ASRock X870 Pro RS WiFi Motherboard

ASRock X870 Pro RS WiFi – A Motherboard for Demanding Users

ASRock X870 Pro RS WiFi is a modern motherboard designed for performance enthusiasts and gamers who value stability, speed, and functionality. Equipped with advanced technology that supports AMD Ryzen™ 9000, 8000, and 7000 series processors, it offers full support for PCIe Gen5 and dual-channel DDR5 memory, delivering incredible overclocking capabilities and top-tier performance. With integrated Wi-Fi 7 and USB4 Type-C ports, the X870 Pro RS WiFi is ready for ultra-fast connections, while features like BIOS Flashback and Automatic Driver Installer make system updates and management easy.

Advanced Power Design and Stable Operation

ASRock X870 Pro RS WiFi offers A 14+2+1-phase power design with Dr.MOS technology ensures stable and efficient power delivery to the processor, essential for intensive tasks like gaming and video editing. The use of an enlarged heatsink armor allows for better heat dissipation, maintaining optimal temperatures even in extreme conditions. This design makes the motherboard not only efficient but also reliable, crucial for users seeking maximum stability while overclocking.

PCIe Gen5 and High-Speed ​​M.2 Connections

With support for PCIe Gen5, the ASRock X870 Pro RS WiFi delivers twice the data throughput of previous generations, ideal for the latest graphics cards and SSDs. The Blazing M.2 supports PCIe Gen5x4 drives, offering incredible data transfer speeds of up to 128Gb/s, making it perfect for advanced tasks and demanding applications. Additionally, the motherboard also supports Hyper M.2 and Ultra M.2, providing even more flexibility in storage configuration.

​​

Ultra-fast Connectivity with Wi-Fi 7 and Dragon 2.5G LAN

ASRock X870 Pro RS WiFi is equipped with Wi-Fi 7, providing incredible throughput and stability for wireless connections. Users can enjoy smooth streaming, lag-free online gaming, and lightning-fast data transfers. Additionally, the Dragon 2.5G LAN card boosts network speeds to 2.5Gbps, significantly surpassing traditional Gigabit LAN, offering faster file transfers, lower latency, and improved connection quality for gaming and content creation.

Impressive Audio with Nahimic Audio

The ASRock X870 Pro RS WiFi is also a motherboard that doesn't disappoint when it comes to audio. Equipped with the Realtek ALC1220 audio codec and Nahimic Audio technology, it delivers incredible sound quality, perfect for gaming, watching movies, or listening to music. Features like impedance detection on the rear audio output and independent PCB layers for left and right channels improve sound clarity and depth, delivering a truly immersive audio experience.

Stylish Design with Polychrome RGB and DIY Features

ASRock X870 Pro RS WiFi also features a modern Polychrome RGB design that allows you to personalize your system lighting with addressable LED headers. Users can easily synchronize the lighting with other devices to create unique lighting effects. Additionally, the motherboard is DIY-friendly, with a tool-less M.2 heatsink design that simplifies SSD installation and cooling management. Reinforced PCIe 5.0 slots provide stable support for even the heaviest graphics cards, making this motherboard perfect for PC enthusiasts.

Specifications

Processor

• Processor Manufacturer: AMD • Processor Socket: Socket AM5 • Processor: AMD Ryzen™ 9000 Series, AMD Ryzen™ 8000 Series, AMD Ryzen™ 7000 Series • Maximum Number of SMP Processors: 1

Memory

• Supported Types Memory: DDR5-SDRAM • Number of Memory Slots: 4 • Memory Slot Type: DIMM • Memory Channel Support: Dual Channel • Maximum Memory Capacity: 256 GB • Unbuffered Memory: Yes • Supported Memory Clock Speed ​​(Max): 8000+ MHz

Memory Controllers

• Supported Hard Drive Interfaces: Blazing M.2 (PCIe Gen5 x4), Hyper M.2 (PCIe Gen4 x4)

Internal I/O

• Number of USB 2.0 Ports: 2 • USB 3.2 Gen 1 (3.1 Gen 1) Ports: 1 • USB 3.2 Gen 2 (3.1 Gen 2) Ports: 1 • Number of SATA III Ports: 4 • Front Panel Audio Connector: Yes • ATX Power Socket (24-pin): Yes • CPU Fan Connector: Yes • RGB LED: Yes

Back Panel I/O Ports

• Number of USB 3.2 Gen 1 (3.1 Gen 1) Type-A Ports: 4 • Number of USB 3.2 Gen 2x2 Type-C Ports: 2 • Number of Ethernet LAN (RJ-45) Ports: 1 • Number of HDMI Ports: 1 • Microphone: Yes • S/PDIF Out Port: Yes • Line Out: Yes • Number of USB 2.0 ports: 6 • WiFi antenna socket: Yes

Network

• Wired LAN: Yes • Ethernet interface type: 2.5 Gigabit Ethernet • LAN controller: Dragon RTL8125BG • Wi-Fi: Yes • Basic Wi-Fi standard: Wi-Fi 7 (802.11be) • Wi-Fi standards: Wi-Fi 7 (802.11be), Wi-Fi 6E (802.11ax), Wi-Fi 4 (802.11n), 802.11g, 802.11b, Wi-Fi 5 (802.11ac), 802.11a • Bluetooth: Yes • Bluetooth Version: 5.4

Features

• Motherboard Chipset: AMD X870 • Audio Chipset: Realtek ALC1220 • Audio Output Channels: 7.1 channels • Motherboard Form Factor: ATX • Motherboard Chipset Family: AMD • Supported Windows Operating Systems: Windows 10 x64, Windows 11 x64 • OS Architecture: 64-bit
