TechniSat UNIX Octo LNB 4K UHD 0.1dB 8 TV decoders

? Powerful capabilities without a multiswitch? Discover the TechniSat UNIX Octo LNB!

Are you building a large home TV network, an installation in a guesthouse or an apartment building? The TechniSat UNIX Octo LNB satellite converter is an uncompromising device that allows direct connection of up to 8 independent receivers using single cables, without the need for expensive, external splitters (multiswitches)!

This model is perfect for extensive installations with four advanced TWIN decoders. Thanks to the lowest possible noise figure (0.1 dB) it guarantees crystal-clear reception of HD and UHD (4K) signals on each of the eight connected screens simultaneously!

? Why choose this model? Discover the key advantages:

• ? Cinema quality in every room – stable and uninterrupted reception of the highest resolution HD and UHD (4K) signals.

• ? Gigantic capabilities (up to 8 users) – connect up to 8 classic decoders or 4 modern devices with a double TWIN recording head.

• ?️ Extreme resistance to outdoor conditions – the hermetic housing protects against moisture, sun, heavy frost and snowfall.

• ⚡ Advanced energy efficiency – despite supporting up to 8 signal lines, the current consumption is only a maximum of 180 mA.

• ? Standard holder diameter – size 40 mm fits perfectly into standard satellite dish mounts.

? Full technical specification:

• Brand: TechniSat

• Model: UNIX Octo LNB

• Article number: 76-4805-00

• EAN code: 4019588764859

• Housing color: Beige / orange

• Number of outputs: 8x F connector (Impedance 75 Ohm)

• Noise figure: 0.1 dB

• Signal gain: 55 dB

• Mounting diameter: 40 mm

⚙️ Frequencies and Control:

• Input Frequency: Lower: 10.7 ... 11.7 GHz | Upper: 11.7 ... 12.75 GHz

• Output Frequency: Lower: 950 ... 1950 MHz | Upper: 1100 ... 2150 MHz

• Local Oscillator: Lower: 9.75 GHz | Upper: 10.6 GHz

• LNB Power Supply: 10.5 ... 19 V

• Current Consumption: Maximum 180 mA

• LNB Polarization Control: Vertical: 10.5 ... 14 V | Horizontal: 16 ... 19 V

• Band switch: 22 kHz

?️ Operating environment:

• Ambient temperature: from -30°C to +70°C

• Permissible air humidity: 10% ... 90%

? Set contents:

• Brand new TechniSat UNIX Octo LNB converter packed in the original box
