Description:
1. Top-Tier Signal Reception Performance: Built with integrated Automatic Gain Control (AGC) circuit and PLL phase-locked loop local oscillation structure, it achieves -107dBm reception sensitivity without frequency offset, effectively removing signal phase distortion caused by unstable signal strength. It maintains stable signal reception even in complicated environments without any reception blind areas, and can be used as a direct replacement for infrared receivers.
2. Industry-Leading Low Power Design: Featuring optimized imported RF chip circuit design, it works with a wide 3.0V-5.5V operating voltage, with operating current as low as 2.5mA@315MHz. It effectively lowers device power consumption, which is perfect for battery-operated portable devices and significantly extends the battery life of your devices.
3. Reliable Anti-Interference & Universal Compatibility: Adopting professional stray radiation suppression process, it offers excellent anti-interference capacity and supports multiple modules running at the same time. It is applicable for harsh industrial control scenarios, lowers product certification costs, and supports stable large-scale deployment.
4. Extreme Temperature Resistant Performance: Adopting industrial-grade electronic parts, it runs stably in the temperature range from -30℃ to 85℃. It functions normally under extremely cold or high-temperature environments, suitable for outdoor, vehicle-mounted, industrial control scenarios with big temperature variations, and ensures long-term reliable operation.
5. Plug-and-Play Integration No External Components Required: Pre-integrated with full superheterodyne receiving circuit, no extra external components are required, and it directly outputs standard CMOS signals for external decoding. It greatly simplifies your product development workflow, cuts down R&D cycles, helps you realize wireless functions for your products quickly and boost product added value.
Specifications:
Type: RF Wireless Receiver Module
Material: FR4 Printed Circuit Board, High-precision Crystal Oscillator, Imported RF Integrated Chip, Gold-plated Pin
Dimensions: 30 x 13 mm
Color: As pictured
Applicable Scenarios: Car remote keyless entry, security alarm system, wireless doorbell, remote garage door, industrial wireless control, wireless toys, smart home control, wireless data transmission
Package Content: 1 x RF Wireless Receiver Module
Note:
1. Please kindly note that the images are for display only, please refer to the listed specifications for actual size information.
2. Slight size error may exist due to manual measurement, thanks for your kind understanding.
3. The actual color may vary a little from the photos due to different monitor settings and lighting effects.
