Longer Laser B1 30W Laser Engraver Cutter, 6-core Laser Head, 450 x 440mm Engraving Area - EU

Longer Laser B1 30W Laser Engraver Cutter, 6-core Laser Head, 450 x 440mm Engraving Area - EU

Highlights

33-36W Output & 6-Core Laser Head

The Laser B1 boasts one of the strongest diode lasers available today.

Highly Concentrated Laser and Improved Cutting Power

The highly concentrated laser beam increases cutting capabilities by 20%, and can cut through 25mm basswood and 50mm acrylic.

Bigger Frame

The Laser B1 boasts a working area of 450 x 440 mm, an increase of 23.75% compared to competitors. This is ideal for A3 panels.

36,000mm/min High Speed

Laser B1 is equipped with a new 32-bit motherboard, which allows engraving speed up to 36,000mm/min, four times faster than ordinary laser engraving machines. In addition, TMC2209 silent drivers is used to effectively reduce the noise of operation, providing a faster and more enjoyable experience.

Smart Air-Assist System

The Air-assist pump can be automatically turned on and off, and is directly controlled by the lightburn, improving the precision and quality when cutting.

Multi-Color Engraving

A high-energy laser beam instantly oxidizes metal, bringing vibrant colors to fulfill your creative needs.

Safety Measures

The B1 boasts eight major safety features including Move/Flame/Offline/Motionless/Security Lock/Eye Protection/Emergency Stop/Zero Reset.

Wide Variety of Uses

The 33W laser can cut or engrave over 1000 different materials, such as wood, steel, leather, silver, acrylic, cloth, and more.

Sturdy Metal Frame

The B1 is made with a sturdy aluminum frame which stays stable even under high-speed working mode.

XY-axis Limit Switches

Limit switches can accurately locate the position of the laser module, allowing for a safety feature where the B1 will trigger an alarm if it detects the laser is moving in the wrong direction.

Laser Lens Protection

The laser module is equipped with a replaceable lens and dust-proof hood which prevents smoke from polluting the lens.

Multiple Data Transfer Options

Supports Wi-Fi, USB, APP and TF cards. The Ray5 is not limited to a physical computer connection.

Software Compatibility

Compatible with LaserGRBL, LightBurn and supports Windows 7+, macOS, and Linux. Supported file formats: JPG, PNG, BMP, G- code, GIF, SVG, NC, GC, etc.

Specification

Brand: Longer Type: Laser Engraver  Model: Laser B1 30W Color: Navy Blue

Laser Technology: Diode Laser Technology Working Area: 450x440mm (17.72x17.32inch) Laser Wavelength: 450-460 nm Focal Length: Fixed Focus-50mm Laser Spot Size: 0.08x0.15mm Optical Output Power: 33-36W Power Max Consumption: 180W Engraver Output: DC 24V 7.5A Engraver Lnput: AC 110-240V, 50/60Hz Z Axis-Height Range: Up to 50mm Fastest Working Speed: Speed 36000mm/min Software: Laser GRBL on XP/7/8/10 (Free), LightBurn on Windows, Mac OS, and Linux Input Image Format: JPG, PNG, BMP, GIF, SVG, AI, etc. Connection Type: USB / TF Card / WiFi / APP Limit Switches: Yes Air Assist Interface: Yes
