Digital Cable Tracker RJ45 PoE++ 90W Optical Power Meter Network Engineering All-in-One Tester LT-200S Port Flashing TDR length

Wireless Function : No High-concerned chemical : none Size : LT-200S Model Number : LT-200S Brand Name : GILEETEEK Origin : Mainland China Certification : CE,FCC,RoHS Display : 3 inch, 48*65mm Optical Power Meter : -70~+10 dBm Visual Fault Locator : Test Range 10KM Working Temperature : -10℃---+50℃ Working Humidity : 30%-90% Cable Length : Max 600m UTP Cable Test : Support PD Powered Detection : Support Port Flashing : Support

Model: LT-200S

Feature ● 3 inch screen, screen size 48*65mm ● Secondary Code Digital Mode: Decisively rejects noise and false signals, locate cables quickly and easily. ● Advanced UTP Cable Test: Test UTP cable's sequence, type and remote kit, quickly detect the near-end, mid-end and far-end fault point of RJ45 cable connector. ● RJ45 cable TDR Test: Test cable’s length, measurement range 600 meter. ● Continuity Test: Emitter, Minimum recognition length of 10cm; Receiver, Minimum recognition length of 1m. ● Short Circuit Detection: Supports network cable short circuit detection. ● Length Measurement: Measures open/short-circuited network cables from 1 to 600 meters. Accuracy: Cable length x 3% ± 1m ● Port Flashing: Search the switch port which connect the meter, and detect the connected network port (100/ 1000M). ● PoE Testing: Supports IEEE802.3BT/AT/AF and non-standard protocol detection. Displays power supply voltage, power supply pins, and pin polarity. Supports PoE input voltage loop-through output. Real-time power can be detected when connected to a load. Online power range, 0~90W. ● PD Power Detection: Detects standard or non-standard PoE, supports 24V and 48V PoE. ● PSE IN and OUT: Measure the PSE power supply voltage and power. ● Optical Power Meter: Wavelength 850/980/1270/1300/1310/1490/1550/1577/1625/1650 nm.

Measurement range, -70 ~ +6 dBm, for optical power testing and Fiber link loss relative measurement. ● Visual Fault Locator: Emit red laser sources to test multi-mode and single mode fiber's bending and breakage, test range 10 KM. ● Emitter: 3 AA Batteries(NOT INCLUDED); Receiver: 2 AA Batteries(NOT INCLUDED).

Application The multifunction cable tester is designed for maintenance and installation of cable, cable tracer, optical power meter and Visual fault locator test in one equipment. The unit supports detect the near-end, mid-end and far-end fault point of RJ45 cable connector, and also supports PoE power supply protocol, measure the PSE power supply voltage and power. Installers and engineers take the all in one cable tester, making working conditions safer and increasing productivity.

● Network cabling project installation and maintenance ● Computer room detection and maintenance Package Include 1) Cable Tester 2) Cable Tracer 3) RJ45 Cable 4) RJ11 Cable 5) Allifgator Clip Cable 6) Screw, Screwdriver 7) RJ45 to BNC Connector 8) Tool Bag/SC, ST Connector 9) User Manual

Wireless Function: No High-concerned chemical: none Size: LT-200S Model Number: LT-200S Brand Name: GILEETEEK Origin: Mainland China Certification: CE, FCC, RoHS Display: 3 inch, 48*65mm Optical Power Meter: -70~+10 dBm Visual Fault Locator: Test Range 10KM Working Temperature: -10℃---+50℃ Working Humidity: 30%-90% Cable Length: Max 600m UTP Cable Test: Support PD Powered Detection: Support Port Flashing: Support
