31ZY Carbon Brush Motor 12V Brushed Electric Motor Reversible Reversible Gear Motor DIY Generator

Label:Yes [Precision Construction and Durable] Made of sturdy metal with precision machined components and pure copper wire coils, this 24 V 8000 rpm motor features low heat buildup and low loss. The carbon brush design helps ensure long service life.

[Wide Application Range] This permanent magnet motor is well suited for reduction gear motors, advertising billboards, string trimmers, electric fans, heating mechanisms, display shelves, crafts, lamps, toys, and DIY projects.

[High Speed and Stable Performance] This 31ZY permanent magnet DC motor delivers a no load speed of 8000 RPM at 24 V with nominal output of 21 W. The brushed motor design helps ensure stable working under nominal frequency, with speed unaffected by voltage changes.

[Reversible CW and CCW Rotation] The DC motor supports both clockwise and counterclockwise rotation by simply swapping the red and black wire connections. Red to positive, black to negative for CW. Red to negative, black to positive for CCW. [Compact Size and Easy Installation] Outer diameter 31 mm / 1.22 in with 3 mm / 0.12 in shaft diameter and 19 mm / 0.75 in shaft length. The 31ZY DC motor features simple wiring and easy mounting for various mechanical equipment and DIY applications.

Specifications: Model:31ZY Color: Black Material: metal Outer diameter: 31mm / 1.22in Shaft length: 19mm / 0.75in Shaftdiameter: 3mm / 0.12in Type(Optional): 12V 4000rpm, 24V 3500rpm, 24V 8000rpm Weight:165g Wiring: CW: red: "+", black: "-" CWW:red: "-", black: "+"

Package includes: 1 xMotor
