SVBONY SV905C Digital Eyepiece Astronomical Guide Camera with CMOS USB 1.25-inch Sensor, 1.23MP, 2.0 Type-C

------------------------------------------------------------------------------------------------------------------ 【Voltage Compatibility】 When using electrical appliances, please note that they are designed for Japanese voltage specifications (90-110V), so if you use them with a different voltage, it may cause a malfunction.

【Plug Type】 Our products use Japanese plug types (A or B type). Please use a conversion adapter if necessary.

【Important Note on Transformers and Adapters】 A transformer adjusts voltage to match your device’s requirements. A conversion adapter only changes the plug shape and does not adjust voltage. Using only a conversion adapter without a transformer may result in damage to the product.

【Liability】 We are not responsible for malfunctions or damages caused by improper use, such as operating the product without a transformer. ------------------------------------------------------------------------------------------------------------------

The SV905C guide camera features an IMX225 1/3" photosensitive chip, a resolution of 1280 * 960, a diagonal of 6.09mm, 1.23 million effective pixels, a pixel size of 3.75μm x 3.75μm, a peak QE value of approximately 80%, and a 12-bit ADC. It features a USB 2.0 Type-C interface, which can be on both the front and rear, making it more convenient. It utilizes the ST4 guide port, which can be connected to the AUTOGUIDE interface of the equatorial mount to control equatorial mount guiding. Its compact form factor allows the camera to be mounted on a 1.25-inch focus mount. The protective window features an anti-reflective coating to maximize light transmission and protect the sensor. Equipped with a limit ring and limit scale, it allows you to fix the focus in the ideal position. This is convenient for quickly and accurately finding the focus position in subsequent use. Compatible with systems such as Windows 7, Windows 10, Mainstream Linux OS, Raspberry Pi, and macOS. Software and drivers are provided. The product has been upgraded, and the issue of the USB interface becoming loose has been resolved. You no longer need to worry about the cable breaking. Description: The SV905C guiding camera is a highly sensitive, fast color astronomical camera for imaging planets, lunar and solar objects, and some bright deep-space objects. This camera is also ideal for "lucky imaging" of planets, double stars, and other compact objects, especially with long-focal-length telescopes. Features: Compact, highly sensitive 1.2-megapixel color camera with a 1/3-inch CMOS 1280x960 sensor, ideal for autoguiding or planetary imaging. Tiny 3.75-micron pixels, high peak QE of 75%, and low readout noise allow for precise tracking of faint guide stars. USB 2.0 Type-C interface and ST4 port for direct connection to the autoguider port on the telescope mount. Compact 36mm diameter form factor allows the camera to slide into a 1.25-inch focuser. Weighs only 60g (2.1oz). AR-coated protective window to maximize light transmission and protect the sensor. Includes M28.5 x 0.6 female thread for astronomical filters. Manufacturer Software and drivers available from the website Specifications: Brand: SVBONY Model: SV905C Sensor: SONY IMX225 USB Type: Type-C USB 2.0 Total Pixels: 1.2 million pixels Diagonal: 6mm Maximum Resolution: 1280 * 960 Pixel Size: 3.75μm * 3.75μm Image Area: 5.6mm * 3.2mm Maximum Frame Rate: 39FPS Shutter Type: Rolling Shutter Exposure Time: 64us-2000s Read Noise: 4.0e QE Peak: 75% Full Well Charge: 13ke ADC: 12-bit Gain: 0-500 ROI Function: Yes Bins: 1x1 2x2 Digital Noise Reduction: HCG Mode Video Format: AVI Communication Interface: DirectShow Interface Application Software Windows OS: Sharpcap, Firecapture, PHD2, ASCOM Platform Linux OS: AstroDMX Capture for Linux Raspberry Pi: AstroDMX Mac OS: AstroDMX Compatible Systems: Windows 7, Windows 10, and mainstream Linux OS, Raspberry Pi, Mac OS Operating Temperature: -5°C to 45°C Storage Temperature: -20°C to 60°C Operating Humidity: 20%RH-80%RH Storage Humidity: 20%RH-95%RH Power Consumption:
