DAC6578 DAC7578 Digital To Analog Converter Module I2C Interface 8 Channel Output EEPROM Power On Reset

Quantity : 1 High-concerned chemical : none Package : SOP is_d : Yes Supply Voltage : 3-5V Type : Module Origin : Mainland China Condition : New Operating Temperature : 0-50C Feature 1 : DAC6578 Module Feature 2 : DAC7578 Module Feature 3 : 8 Channel I2C DAC Feature 4 : I2C Digital Analog Converter Feature 5 : 3-5V Wide Voltage DAC Breakout Feature 6 : 8 Channel Programmable Voltage Output Module Feature 7 : EEPROM DAC Module With Power On Reset Feature 8 : Sensor Bias Voltage Setup Board Feature 9 : Automation Test Signal Generator Module Feature 10 : 10 12 Bit DAC Module

Product Features: 1. Equipped with high-performance DAC chip, I2C communication, compatible with STEMMA QT/Qwiic interface 2. Multi channel independent programmable voltage output, built-in buffer amplifier, stable output performance 3. Supports 3 5V wide voltage supply, compatible with various main control systems of 3.3V and 5V 4. Equipped with power on reset function, some models come with EEPROM to save configuration parameters 5. Suitable for development scenarios such as signal generation, equipment calibration, sensor bias, etc

DAC6578 Breakout -8-channel 10 bit I2C DAC module compatible with STEMMA QT/Qwiic interface Basic Parameters Number of channels: 8 independent outputs Resolution: 10 bits (1024 levels) Output voltage: 0V~VDD (supply voltage) Supply voltage: 3V~5V Interface: I2C (0x4C) Module size: 30mmx17.8mm x5mm

Core functions: 8-channel independent voltage output 10 bit resolution analog-to-digital conversion I2C interface control Built in output buffer amplifier Module integrated level conversion circuit Each channel is independently programmable Power on reset to zero output Compatible with 3.3V/5V control systems

Main purpose: Multi channel analog signal control Automated testing system Waveform signal generation Sensor bias voltage setting

DAC7578 8-channel 12 bit I2C DAC module compatible with STEMMA QT/Qwiic interface

Basic Parameters Number of channels: 1 output Resolution: 12 bits (4096 levels) Output voltage: 0V~VREF (2.5V/5V optional) INL: ± 2 LSB (maximum value) Supply voltage: 3V~5V Interface: Compatible with STEMMA QT/Qwiic (I2C address configurable) Module size: 30mmx17.8mm x5mm

Core functions: Single channel 12 bit high-precision analog-to-digital conversion 2.5V/5V internal reference voltage source Non volatile storage (EEPROM) saves settings Compatible with STEMMA QT/Qwiic interface, plug and play Plug and play: STEMMA QT/Qwiic interface, no need for soldering High precision: 12 bit resolution, extremely low noise Internal benchmark: Integrated 2.5V/5V precision reference source Open source ecosystem: providing mainstream open source platform drivers

Main purpose: Precision programmable voltage source Calibration of automated testing equipment Sensor excitation signal generation High precision bias voltage control

Packing List Module X1

Needle X1 label:yes
