High-Voltage Generator Module Arc Igniter DC 3.3V-5V to DC15-30KV No-Load High-Power High-Voltage Boost Module High-Voltage Coil

<kse:widget data-widget-type="customText" id="1005000020377202" type="custom"></kse:widget> <kse:widget data-widget-type="customText" id="1005000019313608" type="relation"></kse:widget>

Features: 1. Wide voltage compatibility: DC 3.3-5V power supply, single lithium battery can also be driven, strong applicability 2. High voltage and high power: output 15-30KV voltage, accurate ignition, adapt to a variety of industrial scenarios 3. High efficiency and low heat: high-voltage high-power boost chip design, long-term operation without heating, stable and reliable 4. Ultra-durable circuit: anti-high voltage design, no damage to the circuit when the high-voltage packet is damaged, long service life 5. Adjustable and flexible output: voltage is freely adjustable to meet the needs of different equipment, high versatility

Parameter: Product Name: Arc Igniter Supply Voltage: DC 3.3V-5V, can also be used 3.7V single lithium battery power supply Output Voltage: about DC 15-30KV, mainly worried about the high-voltage package and the device's voltage, the circuit can be arbitrarily raised and lowered circuit boosting Module Size: 61.5x21mm Wiring: red wire to the positive pole, black wire to the negative pole

Using high-voltage high-power boost chip XKT-203 IC design, with a simple circuit, high output power, output voltage arbitrarily adjustable, high efficiency and other characteristics, the output voltage of 2 ~ 30,000 volts or so, the circuit does not heat up for a long time, the circuit is durable, there are customers for a long time to apply, due to the power of the high-voltage packet cracks, the circuit will not be damaged.

Package include: Module x1

Brand Name: diymore Quantity: 1 Package: TQFP is_customized: Yes semi_Choice: yes High-concerned chemical: none Origin: Mainland China Type: Module Supply Voltage: DC 3.3V-5V Choice: yes
