BAOFENG BF-771 SMA-Female VHF UHF Dual Band Antenna For Baofeng UV 5R UV-5RH UV-K6 Quansheng UV K5 (8) Walkie Talkie Radio

【Compatible Model】Compatible With Baofeng UV-5R UV-5RH AR-5RM UV-17PRO UV-21PRO UV-5RH UV-25 UV-82 UV-13PRO K5Plus GM-15PRO;Quansheng: UV K5 UV-K5 8UV K6 K58 TG-UV2 Plus;Abbree: AR-819 AR-F1 AR-F2 AR-F3 AR-F5 AR-F6 AR-F8 【 Features】 Connector Type: SMA Female Head; Frequency range: dual frequency 144/430MHz; Gain: 2.15dBi; Maximum power: 20W; V. S.W.R value: less than 1.5; Impedance: 50ohm 【Durability& Stronger Signal】This antenna has a total length of 14.96 inch/38 cm, is lightweight and easy to carry, and is an essential equipment for outdoor camping. 【Flexibility】It has good flexibility, can be easily bent, and is lightweight, making it easy to carry during hunting or camping. 【Multiple Usage】Antennas with high gain characteristics can effectively enhance communication coverage and are suitable for various indoor and outdoor environments, including camping and self driving travel.

Specification 100% brand new and high quality Model BF-771 PRO

Band Dual band VHF/UHF(UHF works better)

Antenna type SMA-F Soft Antenna

Frequency 144/430Mhz(136-174+400-470)MHz

Gain 3 dB

Max power 20 Watts

VSWR Less than 1.5 Downwards

Impedance 50ohm

Connector Type SMA-F(Female)

Omni Polarization Vertical

Radiation Omni

Material ABS and Heat shrinkable sleeve

Length 38 cm/14.96 In(approx)

Weight 34g/1.19oz

Color Black

Widely used on handheld Radios with SMA male interface

Applications model: For BAOFENG/Pofung BF-666S,BF-777S,BF-888S,UV-5R,BF-F8HP,UV-5RH,UV-5RM,UV-13PRO,M-13PRO,UV-17PRO,UV-21PRO,UV-25PRO,UV-K5,UV-K6,UV-82,M-5R,UV-18PRO,UV-S9Plus,GM-15PRO,UV-5G Plus,AR-152,DM-1701,DM-1801

For QUANSHENG

TG-K4AT,TG-K100,TG-K200,TG-K58Mini,TG-6A,TG-5A,TG-620,TG-5A Plus,TG-K4AT(UV),TG-360,UV-K5 K6 UVK5(8).

For ABBREE AR-730,AR-830,AR-869,AR--F8,AR-518,AR-F5

For Kenwood TK-360,TK-370,TK-370G,TK-372,TK-372G,TK-3100,TK-3140,TK-3160,TK-3170,TK-3180,TK-3200,TK-3202,TK-3207

For RETEVIS

H-777,RT-B6,888s Plus,RT5,RT6,RT7,RT21,RT23,RT25

For most SMA-Female Connector Radio

Package Includes: ● 1/2/5/10 x BF-771 PRO Antenna

Brand Name: BAOFENG Item Type: Antenna Origin: Mainland China Model Number: BF-771PRO Choice: yes
