Induction heater Nut and bolt heater Inductor 2000 2kVA 230V

Induction heater Nut and bolt heater Induktor 2000 2kVA 230V

☑️ The heater set includes:

• ⭐ Schwarz Induktor 2000 device

• ⭐ Ergonomic coil holder

• ⭐ 230V power cable

• ⭐ Set Coils:

1. ➡️ Straight spiral coils - 2 pcs.

2. ➡️Flat coil - 1 pc.

3. ➡️Flexible coil - 1 pc.

4. ➡️Focusing coil - 1 pc.

• ⭐ User's manual in Polish

☑️ Schwarz Induktor 2000 induction heater – a compact and effective solution

• ➡️ Schwarz Induktor 2000 is a professional induction heater with a power of 2 kVA, with a voltage of 230 V.

• ➡️ Induction technology is a modern solution that eliminates the need to use burners gas, ensuring fast, safe and precise heating of metal elements.

• ➡️ Coils with copper windings guarantee even heat distribution.

☑️ Technical data

• ⭐ Input voltage: 230V ±10% (50/60Hz)

• ⭐ Maximum input power: 2 kVA

• ⭐ Output power: 1.90 kVA

• ⭐ Input current: max. 8 A

• ⭐ Power factor: 0.99 PFC

• ⭐ Operating time: 1.5 min heating / 1.5 min cooling

• ⭐ Protection class: IP20

• ⭐ Heater weight & handle: 2.9 kg

• ⭐ Total weight: 4.29 kg

• ⭐ Manufactured in: European Union

• ⭐ CE compliant

• ⭐ Power cable: 150cm

• ⭐ Induction cable: 86cm

☑️ Versatile use in workshops and services

➡️ Schwarz Induktor 2000 uses electromagnetic induction to quickly and locally heat metal elements.

• ⭐ Loosening seized screws and nuts

• ⭐ Removing stickers, adhesives and putty

• ⭐ Straightening dents in the bodywork

• ⭐ Heating sensors, pins, connectors

• ⭐ Use in hard-to-reach places

☑️ Benefits of use

➡️ The device eliminates the need to use gas burners, which significantly increases work comfort and safety.

• ⭐ No open flame - lower risk of fire and burns

• ⭐ No need to purchase and store gas cylinders - savings and convenience

➡️ Schwarz Induktor 2000 works with a wide range of coils matched for various applications. Thanks to interchangeable tips, you can choose the right shape and diameter for a specific task.

☑️ Step-by-step operation of the Schwarz Induktor 2000

➡️ The device is activated by the button on the handle – heating only occurs while you hold it.

➡️ Heating is non-contact - a 3–5 mm gap between the coil and the material is enough.

• ⭐ Choose the appropriate coil for the element

• ⭐ Connect to a 230V socket and turn on the main switch

• ⭐ Heat for max. 1.5 minutes, then wait 1.5 minutes for cooling

• ⭐ Move the coil during operation for even heating

• ⭐ After operation, leave the device to cool down with the fan active

• ⭐ Be careful - heated elements may cause burns

☑️ Safety and durability of use

➡️ The device is equipped with safety devices Overload protection and cooling system activated automatically.

• ⭐ Temperature sensor with diodes indicating the operating status

• ⭐ High resistance to overheating

• ⭐ Mandatory gap between the coil and the material: 3-5 mm

☑️ Safety and LED indication

➡️ The LED indication system informs the user about the status Devices:

• ⭐ Green – ready to work

• ⭐ Orange – work

• ⭐ Red (flashing) – overload

• ⭐ Red (steady) – overheating

• ⭐ White – work lighting

• ⭐ Red-white flashing – missing or damaged coil

☑️ Convenience of use and ergonomics

➡️ The device enables fast and trouble-free operation - just plug it into the socket and turn it on.

• ⭐ Short preparation time - no need to light and adjust the flame

• ⭐ Intuitive operation - ON/OFF button and fast heating response

• ⭐ Coils can be easily replaced - depending on the application

☑️ Heater coils included:

1️⃣ Flat coil:

• ⭐ for removing moldings, stickers

• ⭐ dismantling glued body panels

• ⭐ replacing windows

2️⃣ & 3️⃣Straight spiral coils:

• ⭐ screws, nuts, bearings

• ⭐ bending pipes and rods

• ⭐ loosening seized screws, pipes

4️⃣Focal coil:

• ⭐ for precise, spot heating of metal

• ⭐ effective in hard-to-reach places (e.g. in a car)

• ⭐ ideal for heating sheet metal, screws, nuts

5️⃣ Flexible coil:

• ⭐ for hard-to-reach places places

Q&A - Frequently asked questions and answers!

♦️ 1.What is the Schwarz Induktor 2000 used for?

• ✏️ It is a compact induction heater with a power of 2 kVA, designed for fast, precise heating of metal: unscrewing seized screws, removing stickers, straightening dents or heating pins and bearings – without the use of an open flame.

♦️ 2.Can the device replace a gas burner?

• ✏️ Yes.

♦️ 3. What power supply voltage is required?

• ✏️ 230 V AC ± 10% (50/60 Hz)

♦️ 4.How long can I heat continuously?

• ✏️ Maximum 1.5 minutes of continuous heating, then a further 1.5 minutes for cooling (duty cycle 1:1). Following this rhythm extends the life of the device.

♦️ 5. What safeguards protect the device and the user?

• ✏️ Temperature sensor with LED indication (green - ready, orange - operation, flashing red - overload, steady red - overheating)

• ✏️ Automatic cooling fan

• ✏️ Overload protection and IP20 housing

✨ These mechanisms increase work safety and protect the device from overheating.

♦️ 6. What are the practical benefits of using an inductor in the workshop?

• ✏️ Schwarz Inductor 2000 saves time, reduces the risk of damage and works with precision – it heats exactly where it is needed. Additionally:

• ✔️ it is light and handy,

• ✔️ ready to work immediately after connection,

• ✔️ works with interchangeable coils adapted to various tasks.

• ⭐ Schwarz Induktor 2000 device

• ⭐ Ergonomic coil holder

• ⭐ Power cable 230V

• ⭐ Coil set:

1. ➡️ Straight spiral coils - 2 pcs.

2. ➡️Flat coil - 1 pc.

3. ➡️Flexible coil - 1 pc.

4. ➡️Focusing coil - 1 pc.

• ⭐ User manual in Polish
