Uni-T Ut890C Ncv Multimeter

Uni-T UT890C NCV Multimeter

The UNI-T multimeter is a modern and precise measurement tool designed for professionals and electronics enthusiasts. It enables quick and accurate measurements of voltage, current, resistance, capacitance, frequency, and temperature.

Thanks to its robust construction, True RMS function and intelligent protections, it guarantees reliability in all operating conditions.

• DC Voltage: 600 mV / 6 V / 60 V / 600 V / 1000 V ±(0.5%+2)

• AC Voltage: 6 V / 60 V / 600 V / 750 V ±(0.8%+3)

• DC Current: 60 uA / 600 uA / 6 mA / 60 mA / 600 mA / 20 A ±(0.8%+8)

• AC Current: 60 uA / 600 uA / 6 mA / 60 mA / 600 mA / 20 A ±(1%+12)

• Resistance: 600 Ohm / 6 kOhm / 60 kOhm / 600 kOhm / 6 MOhm / 60 MOhm ±(0.8%+3)

• Capacitance: 6 nF / 60 nF / 600 nF / 6 µF / 60 µF / 600 µF / 6 mF / 60 mF / 100 mF ±(3%+10)

• Frequency: 9.999 Hz~9.999 MHz ±(1%+5)

• Temperature: -40°C~1000°C; -40°C~1832°C ±(1%+5)

• Transistor hFE Measurement

• Diode Test

• Continuity Checking

True RMS Function

True RMS is a key function of the UNI-T meter, enabling accurate measurement of the effective value of voltage and current even with distorted waveforms. Thanks to this, the device precisely reads signals from converters, inverters, and switched-mode power supplies, where traditional meters fail.

True RMS guarantees reliable results regardless of waveform and load type.

NCV Function – Non-Contact Voltage Detection

NCV allows you to quickly and safely check the presence of voltage without having to touch the wires. Simply bring the meter's sensor close to the tested point and a light and sound signal will indicate the presence of an electric field.

It is an ideal solution for quick installation diagnostics, ensuring convenience and full user safety.

• NCV (electric field detection function)

• Manual change of measurement ranges

• True RMS

• Fuse blown notification

• Overload notification: >= 20 A

• REL mode: zero reading

• Freeze last reading

• Backlight Display

• Maximum/minimum value recording

• Sound and light signal: during continuity and NCV measurement

• Automatic power-off

• Low battery indicator

• Maximum reading: 6000

• Power supply: 2x 1.5 V AAA batteries

• Display size: 56.5 x 36 mm

• Product dimensions: 183x88x56 mm

• Product weight: 346 g

• Operating Temperature: 0°C ~ 40°C (32°F ~ 104°F)

• Storage Temperature: -10°C ~ 50°C (14°F ~ 122°F)

• Relative Humidity: 0°C ~ 30°C =<75%, 30°C ~ 40°C =<50%

• Operating Altitude: 0~2000 m
