Vandal-proof camera Ahd, Hd-Cvi, Hd-Tvi, Pal Hac-Hdbw1500E-0280B-S2 - 5Mpx 2.8Mm Dahua

VANDAL-PROOF CAMERA AHD, HD-CVI, HD-TVI, PAL HAC-HDBW1500E-0280B-S2 - 5 Mpx 2.8 mm DAHUA

Megapixel camera with 1/2.7" CMOS sensor and AHD / HD-CVI / interface HD-TVI/PAL Interface AHD / HD-CVI / HD-TVI enables the transmission of analog video signals via coaxial cable at a maximum resolution of 8 Mpx (4K UHD).

There is no delay during transmission and the original, high image quality is maintained. When transmitting video using twisted-pair cables and impedance-matching transformers, it is important to consider the possibility of signal reflections and signal crosstalk.

The camera meets the IP67 protection class.

• Standard: AHD/HD-CVI/HD-TVI/CVBS

• Sensor: 1/2.7 " Progressive Scan CMOS

• Matrix size: 5Mpx

• Resolution: 2880 x 1620 - 5Mpx@HD-CVI: Image format 16 : 9 ,2560 x 1440 - 3.7Mpx,1920 x 1080 -1080p,960 x 576 -960H,PAL

• IR illuminator range: 30 m

• IR illuminator power adjustment: Automatic

• Lens: 2.8 mm, F1.85

• Viewing angle: 98 ° (manufacturer's data), 103 ° @HD-CVI/ 90 ° @AHD/HD-TVI (our tests)

• Cooperation with IR illuminator: ICR - Mechanical infrared filter

• Video output: AHD/HD-CVI/HD-TVI/CVBS, 1Vpp/ 75 Ω

• On-screen menu: OSD menu available via the recorder

• Power supply: 12 VDC/ 330 mA

• Power consumption: ≤ 4.2 W

• Housing: Dome, Metal

• Color: White

• Ingress protection: IP67

• Vandal-proof: IK10

• Operating temperature: -40 °C ... 60 °C

• Weight: 0.33 kg

• Dimensions: Ø 110 x 81 mm

• Supported languages: Polish, English, French, Spanish, German, Portuguese, Russian, Italian

• Manufacturer / Brand: DAHUA

• Warranty: 3 years

• D-WDR - Wide dynamic range of lighting

• 2-DNR - Digital Image Noise Reduction

• BLC - Configurable Backlight Compensation

• HLC - High Light (Spot) Compensation

• ICR - Mechanical Infrared Cut Filter

• AGC - Automatic Image Gain Control

• Day/Night Mode

• Automatic White Balance

• Privacy Zones

Note: The cameras we sell do not include power supplies, with some exceptions. This can be verified in the photos available in the auction.
