Duplex Next 2in1 Linear Drain 60 Double-Sided Chrome

• Own brand: BALNEO

• Line: Duplex Next

• Drain type: Linear

• Length: 60 cm

• Material: Stainless steel

• Color: Chrome

• Flow rate: 56 l/min

• Minimum installation depth: 52 mm

• Drain diameter: 40 mm

• Drain cover width: 6.3 cm

• Round collar: 2 cm

• Possibility of gluing in tiles: Yes

• Rotary siphon: No

• Finish: Brushed stainless steel

• Grate: SMOOTH PANEL (reversible panel - possibility of installing tiles or leaving a smooth panel with a brushed stainless steel structure).

• Siphon: Ø40(capacity up to 55 l / min) equipped with a basket-type sediment trap to retain impurities. The sump is easily cleaned from above.

• Minimum installation depth: 52 mm (means that there are almost no limitations in the use of the drain due to the thickness of the ceiling)

• Sealing sleeve: included

• Mounting feet: included (thanks to the adjustment, it is possible to easily install the drain in the floor).

• Spacers: included (the spacers ensure a perfectly even position of the grate and muffle the noise created when water falls directly onto the drain)

• Hook: included (thanks to which the grate of the linear drain can be easily and safely lifted)

• Reduction 5/4 cm: included (thanks to the reduction, we can adapt the drain to the appropriate pipe diameter of 4 or 5 cm)

• Material: the highest quality stainless steel - AISI304 + ABS.

The double-sided linear drain DUPLEX NEXT is designed for installation with ceramic tiles or marble. BALNEO drains are recommended for installation in shower cabins. Thanks to their design and minimum installation height of 52 mm, it can be installed anywhere on the floor.

The drains have a double-sided panel with two purposes: we can glue a tile or leave a smooth panel with a brushed stainless steel structure).

☑️ Drain with a 2-in-1 function

The linear drainhas a 2-in-1 function (tile or panel installation):

• Possibility of installingtile, which allows you to hide the drain and obtain a smooth, consistent surface floor.

• Possibility of mounting a panel, which allows it to be adapted to the design of any bathroom.

☑️ Large basket type sedimentation tank - less cleaning

We used a large basket type sedimentation tank in our drain. This means that thanks to the increased collecting space, the need to clean the settling tank is up to 4 times less frequent compared to other models with a standard tank.

☑️ Easy installation

Thanks to the adjustable height of the legs, the drain can be easily installed in the floor, and the low installation height means that there are almost no limitations in the use of the drain due to the thickness of the ceiling.

☑️ Improved design

Linear drain NEXT is an improved version of our most popular linear drain with a monolithic steel construction.

While maintaining a low installation height (only 52mm), the steel chamber has been enlarged, which allows for the installation of a wider siphon. This solution increases the drain capacity to 55l/min.

☑️ Create a bathroom in one shade

With us, you can easily collect all the products you need to finish your bathroom. When you buy from us you are guaranteed that every product will be in the same color shade.

☑️ Drains with Hygienic Certificate

BALNEO linear drains have a Hygienic Certificate issued by the National Institute of Hygiene (PZH). This gives you the assurance that the drains meet high sanitary requirements and are therefore easy to keep clean.
