TechniSat CoaxSat 120 RG6 Coaxial Antenna Cable 100m Cu Copper 4K

? Uncompromising 120 dB signal – Professional TechniSat CoaxSat 120 copper coaxial cable (100m roll)

Are you looking for a cable that will flawlessly cope with the most difficult installation conditions and provide a crystal-clear image without any losses? TechniSat CoaxSat 120 (catalog number: 0004/3107) is the top shelf among RG6 class coaxial cables.

Designed for professional satellite, terrestrial, and cable networks, it utilizes a 1.13 mm pure copper core and powerful, 4-layer shielding.

In modern buildings, where walls are packed with cables and the air is bursting with Wi-Fi, LTE, and 5G signals, standard cable is simply not enough. CoaxSat 120 offers an incredible 120 dB shielding efficiency, meaning complete immunity to electromagnetic interference.

It's an investment in peace of mind – once installed, the cable will fully support 4K, 8K, and HDTV signals, squeezing 100% of the potential from your home theater.

Why is TechniSat CoaxSat 120 the absolute top of the premium segment?

• Thick 100% Cu wire (1.13 mm): Pure copper with increased diameter guarantees ultra-low attenuation, which allows for lossless signal transmission over very long distances.

• ?️ Powerful 120 dB shielding: Up to four protective layers (foil/braid/foil/braid) create an armored barrier that completely cuts off the installation from external noise.

• ? Class A+: Official certificate confirming the highest telecommunications parameters and compliance with the most stringent European standards.

? 4-Way Shielded Design - No More "Pixelosis" on the Screen

The largest players on the installation market know perfectly well that cheap cables generate costs in the form of later corrections and complaints. Poor shielding is the main reason for annoying image stuttering, especially on HD and 4K channels.

In this cable, TechniSat has used an uncompromising insulation system:

1. Two layers of dense braiding ensure mechanical strength and excellent ground conduction.

2. Two layers of aluminum foil tightly close the cable structure, creating an impenetrable barrier for LTE/5G radio waves.

3. Flexibility and comfort: Despite such an advanced design with an outer diameter of 6.9 mm, the cable fits perfectly in conduits and corners thanks to the ductility of pure copper.

? Technical data and parameters

• Manufacturer: TechniSat

• Model: CoaxSat 120 (4.6)

• Catalog number: 0004/3107

• Length on reel: 100 meters

• Cable class: RG6 / Shielding efficiency class A+ (Class A+)

• Shielding efficiency: 120 dB

• Screen construction: 4-layer (4-Way Shielded: foil + braid + foil + braid)

• Inner conductor: 100% Cu (pure copper (anaerobic)

• Main conductor diameter: 1.13 mm

• Cable outer diameter: 6.9 mm

• Wave impedance: 75 Ohm

• Compatibility: DVB-S/S2 (Satellite), DVB-T/T2 HEVC (Terrestrial), DVB-C (Cable)

• Resolution support: 4K Ready, 8K Ultra HD, HDTV, 3D

• Meter markings: Printed on the cable for precise counting of sections

• Certificates: CE mark, Class A+
