Screws for sandwich panels with steel washer and EPDM gasket
Designed for fastening sandwich panels to steel structures up to 6 mm thick
The most important parameters
• Model: GT 6 SP Z19
• Screw length:175 mm
• Thickness of boards that can be mounted:120-150 mm
• Drilling capacity in steel:up to 6 mm
• Socket:SW8
• Material:hardened carbon steel, galvanized
• Class corrosion: C1-C3
• Color: RAL 9010
• Package: 100 pcs
Original Product of a Reputable Company Etanco®
Additional significant anti-corrosion protection and a perfect match to the RAL/NCS color. UV stabilizers ensure color consistency even after several years, and the modern Powder.coat powder coating technology ensures the coating's durability during installation and a long service life.
2. EPDM washer
Made of the best sealing material - EPDM. It does not lose elasticity over time and has a very long aging period. Resistant to changing weather conditions and UV radiation. After installation, it self-vulcanizes to the sheet metal, creating a tight connection.
3. Hexagonal head with marking
The hexagonal head ensures easy and secure screw installation, which significantly simplifies work and increases installation efficiency. The distinctive marking of ETANCO products allows for easy recognition; each production batch receives a unique number, which enables precise identification.
4. Thread under the screw head
An additional thread with an increased diameter ensures proper distribution of the EPDM washer on the thin cladding sheets of the sandwich panel.
5. 12 μm galvanized coating
Provides effective anti-corrosion protection under standard C1 and C2 operating conditions.
6. Self-drilling tip
Significantly improves the installation process by eliminating the need for pre-drilling holes. GT 6 screws can handle steel up to 6 mm thick.
• for steel structures up to 6 mm thick
1. Base material: cold-formed steel profile
2. Screw socket: SW8
3. Maximum drilling capacity: 6 mm
4. Anti-corrosion coating type: galvanized (corrosive environment C1-C2), galvanized + powder.coat (class C1-C3)
7. Tightening torque: 5 Nm
8. Recommended rotation speed during screw installation: 1500 rpm
9. Thickness range of used boards:120-150 mm
10. Minimum thickness of steel substrate: 1 mm
12μm galvanized coating
All our products have current reference documents developed in cooperation with renowned research institutes.
The products we offer are characterized by the highest quality and can be safely used in construction. We make every effort to ensure that the products delivered to our contractors are safe and adapted to specific tasks.
The auction applies to screws in RAL 9010 color.
Other colors and sizes are available in our other auctions.
*Due to different monitor settings, colors may differ from reality, therefore the presented colors are indicative.
*The measuring cup is not included in the set and is only used for better product presentation.
Allows the use of fasteners in environments with an atmosphere corrosivity class: C1, C2 according to the PN-EN ISO 12944-2:2001 standard.
