Anemometer - wind gauge WT82B

WINTACT WT82B BLUETOOTH ANEMOMETER

PRECISE WINDOMETER WITH BLUETOOTH COMMUNICATION FUNCTION

The anemometer is a practical device for measuring the intensity and strength of wind flow and air movement.

The built-in BLUETOOTH function allows you to save and analyze results in a mobile application compatible withAndroid 5.0 and higher systems.

1. Simultaneous measurement of temperature and air speed

2. Measurement Maximum/Average/Current Air Velocity

3. Two Air Temperature Units: ℃/℉

4. Five Air Velocity Units to Choose From: m/s, Km/h, ft/min, Knots, mph

5. Beaufort Scale

6. Result Hold

7. Backlit LCD Display

8. Manual or Automatic Power Off

9. Chilling Indicator

10. Low Battery Indicator

11. Bluetooth Communication (WT82B only)

12. Data Storage

The product is distinguished by very good measurement precision thanks to the use of a modern sensor and a 6-arm rotor. The fan (blades) built into the housing allows for measuring even very low speeds.

Made of high-quality materials, the device is resistant to shocks and damage, while also being comfortable and handy to use.

The built-in clear and transparent LCD display with blue backlight allows for taking measurements even in the absence of light.

The built-in BLUETOOTH function allows you to save and analyze results in a mobile application compatible with Android 5.0 and higher.

Thanks to the mobile application, you can analyze the measurements and save data in real time.

The application displays data from the actual measurement of wind speed and air temperature on a graph. It also allows you to return to the data at a later time and delete unnecessary measurements.

Data can be saved and stored in the phone's memory, as well as exported to datasheets and transferred to a computer.

The application is compatible with devices running Android 5.0 and higher.

Clear interface, precise graphs, intuitive operation, these are the main advantages of the AnemoMeter

application dedicated to the device

DESCRIPTION OF DISPLAY ELEMENTS

1. Beaufort Scale

2. Data Storage

3. Result Hold

4. Automatic Power Off

5. Power Supply

6. Sensation Indicator Cooling

7. Measured speed

8. Air speed unit

9. Air temperature unit

10. Bluetooth communication icon (for WT81B)

11. Air temperature

12. Low air speed

13. High air speed

14. Average air speed

15. Highest recorded air speed

1. Air Speed ​​Measurement

• Range: 0-30 m/s / 0-5860 Ft/min / 0-55 Knots / 0-90 Km/h / 0-65 Mph

• Resolution: 0.1 m/s / 19 Ft/min / 0.1 Knots / 0.3 Km/h / 0.2 Mph

• Measurement Threshold: 0.6 m/s / 120 Ft/min / 1.2 Knots / 1 Km/h / 1.5 Mph

• Accuracy: ± 5% ±0.1 m/s / ± 5% ±20 Ft/min / ± 5% ±0.2 Knots / ± 5% ±0.4 Km/h / ± 5% ±0.2 Mph

2. Air temperature measurement

• Range: -10°C - +45.°C (14°F-113°F)

• Resolution: 0.1°C (0.18°F)

• Accuracy: ± 2°C (± 3.6°F)

• Condition: Brand new

• Dimensions: 190 x 56 x 36 mm

• Power supply: 3 x 1.5V AAA batteries (included)

• Power consumption: about 7mA with display backlight and about 15mA with Bluetooth function

• Temperature sensor: Negative temperature coefficient resistance

• Operating temperature: -10°C - +50°C (14°F - 122°F)

• Storage temperature: -40°C - +60°C (-40°F - 140°F)

• Operating humidity: below 90% RH

• Tripod mounting hole: 1/4" thread (fits most tripods and monopods available on the market).

2. LCD display

3. Mode button

4. Power and backlight button

5. Unit selection button

6. Tripod mounting hole

7. Battery cover

• WINTACT WT82B anemometer

• 3 x AAA battery, 1.5V

• User manual in Polish

• Original packaging manufacturer

About the BENETECH brand

BENETECHis a manufacturer of advanced measurement and control equipment. A specialized supplier of professional, digital measuring tools and other electronic devices.

BENETECH POLANDis an authorized and direct distributor of this brand in Poland and Europe.

The brand's catalog includes:

• pyrometers and thermal imaging cameras,

• anemometers (wind gauges),

• hygrometers and humidity meters,

• gas and air quality detectors and meters,

• sound meters (decibel meters) and lux meters (light meters),

• laser rangefinders and tachometers,

• thermometers and manometers,

• thickness and vibration meters (vibrometers),

• tools for electricians and cable detectors,

• electromagnetic radiation meters,

• home and industrial electronics devices.

Scan the QR code from this listing to download the current software version for Android devices.

At the customer's request, we attach a calibration report from the manufacturer translated into English. We receive the document electronically a few days later. To avoid delays in order fulfillment, we send the calibration report within approximately 7 business days to the email address provided in the order or assigned to your account.

The manufacturer's calibration report is a free, optional document and is therefore not included in this offer.
