GSM Alarm RED III BOX + Plate + SIM

McDowell GSM RED III Home Alarm

Security at home, in the office or at work is the most important thing. Ensure a good night's sleep and don't worry about your family or business. Invest in the RED III home alarm from McDowell, which has all the most necessary functions.

• use of GSM technology (mobile wireless network GSM and fixed PSTN networks);

• integrated digital voice and SMS messaging;

• self-learning communication code wireless;

• possibility of remote control of the alarm;

• Ni-Hi battery guaranteeing operation of the alarm during a power cut (an SMS message is sent);

• built-in loud speaker and power LED;

• quick and self-installation;

• automatic voice or SMS message about the incident;

• clear LCD display;

• possibility of connecting 150 sensors (support for 150 remote controls);

• quick integration with door, smoke, gas sensors, emergency buttons, etc.;

• ideal for homes, offices, schools, factories, shops, etc.;

• possibility of checking the status and call log on the panel;

• possibility of setting 8 types of inputs (normal, stay, intelligent, emergency, closed, senior assistance, welcome and chime);

• four sets for disarming/arming the alarm;

• alarm numbers and SMS stored in EEPROM memory (no possibility of data loss even after a power failure);

• wireless coding for adding or removing accessories;

• long-range telephone control.

Up to 99 defense zones classified into 8 types

With the McDowell home alarm, you can sleep soundly. The device guarantees up to 99 defense zones, which can be set according to 8 types: normal, home, intelligent, emergency, closed, welcome, assistance for seniors, gong.

Each of them operates on specific principles, making using the alarm completely safe and comfortable.

Quick and self-installation

There is no need to call professionals, as the McDowell home alarm can be installed by yourself. All the necessary information can be found in the user manual in Polish.

Intuitive alarm remote control

The remote control has 4 essential buttons that allow you to arm (closed padlock) and disarm (open padlock) the alarm, as well as put it in standby mode (capital letter S) and, of course, call for help (bell symbol).

Remote alarm control option

The alarm can be controlled remotely without any major problems. All the codes needed for this can be found in the user manual in Polish.

1x PIR Motion Sensor

It is the most popular motion sensor on the market. The sensor can be purchased separately on our auctions. The sensor has a battery with different charge levels.

1x Window-Door Opening Sensor

The window-door sensor is used in alarm systems to wirelessly signal window or door opening.

The kit consists of a reed switch sensor and an external magnet installed on the window or door sash. Opening the sensor sends information about the alarm being triggered. The complete kit consists of:

1. An element containing a magnet

2. An element containing a reed switch

3. Batteries with different charge levels

2x Alarm remote control

We add 2 keychain-shaped remote controls to each standard set. The set consists of 4 buttons indicating:

1. arming the alarm

2. disarming the alarm

3. help button

Wired sound siren

• Thickness: 1.5 mm

• Dimensions: 29x20 cm

• Laminated with foil

• Made of PVC board

You get a free PLUS starter - worth PLN 5!

• Model: WL-JT-99CSF

• Input voltage: DC 9V-12V

• Current in standby mode: < 25 mA

• Current in alarm mode: < 450 mA

• Wireless Frequency: 315/433/868/915 MHz, 2262/1.5-4.7M, EV1527/300K

• GSM Frequency: GSM 850/900/1800/1900 MHz

• Radio Frequency: 10 dBm (10 mW)

• Backup Battery: Ni-Hi AAA*6 DC 7.2V

• Alarm Volume: 110 dB

• Power supply: 1x 9V 6F22 battery (included)

• Current consumption during standby: 0.015 mA

• Current consumption during transmission: 10 mA

• Signal transmitting frequency: 433 MHz ± 0.5MHz

• Detection area: 5-12 m

• Max. distance from the control panel: up to 30 m

• Moving object detection: 0.3 - 3 m/s

• Motion detection range: Horizontal: 110° / Vertical: 60°

• Dimensions: 11 x 5.5 x 3.5 cm

Window/Door detector specifications:

• Power supply: 1x DC12V/23A battery

• Power consumption in standby mode: 15 mA

• Power consumption in operation mode: 20 mA

• Signal transmission frequency: 433 MHz ± 0.5MHz

• Max. distance from the control panel: up to 30 m

• Maximum internal distance: 15 mm

• Operating conditions: -10ºC ～ +40ºC

• Dimensions:7 x 3.5 x 1.5 cm

1. RED III alarm control panel

2. 1x wireless PIR motion sensor (with battery)

3. 1x wireless door/window opening motion sensor (with battery)

4. 2x remote control unit

5. 1x wired sound siren

6. 1x telephone cable

7. 1x PVC plate

8. Power supply

9. Starter PLUS worth PLN 5

10. Polish user manual
