Dia Turbo Cutter Z3+1 12X20X12Mm 7+1Pcd /Board/Mdf

ITA TOOLS DIA TURBO MILLING CUTTER / Densimet BODY / 3 spirals

• D = 12 / H = 2.5 (can be resharpened 2 - 3 times)

• D = 16 - 18 / H = 4 (can be resharpened 5 - 6 times)

• D = 20 - 25 / H = 4.5 (can be resharpened 5 - 6 times)

DIA milling cutter for high-speed feeds with PCD (PKD / Industrial Diamond) blades mounted in a spiral Carbide-tipped. The body is made of the highest quality densimet. For use on CNC or top-spindle milling machines.

The appropriate blade geometry ensures that the teeth press the upper laminate from above and the lower laminate from below, minimizing laminate tearing. - Used for working with wood, chipboard, MDF, and plastics.

It has a DIA drilling blade.

• Diameter (D [mm]): 12.00

• Working height (I [mm]): 20.00

• Shank diameter (S [mm]): 12.00

• Total length (L [mm]): 69.00

• BODY (BODY): DENSIMET

• Number of teeth (Z): 7 PCD +1 PCD

• Rotation (ROTATION): RH - right

• Three full blades distributed on three spirals

• Body with durable steel or DENSIMET

• DIA drilling blade

• Feed rate up to 25 m/min

MADE IN POLAND

DIA insert height: 2.5 mm Application: For cutting and formatting materials such as raw chipboard, laminated on one or both sides or covered with a melamine film, MDF.
