DOMRAEM ESP32 4 Output WLED Controller 16A Fuse & Level Shifter Sound Sync Compatible with WS281x Digital RGB IC LED Strip Light

Is Smart Device : Yes High-concerned chemical : none Features : WLED APP Control Model Number : DOM-WLE-RC005 DOM-Z-103 DOM-Z-104 Oscillation frequency : 50-60HZ Warranty : 2 years Certification : ce,EMC,FCC,LVD,ROHS Voltage : 5-24V Material : ABS Wattage : 384W Power Source : Max. Load Power : 384W Remote Distance : 30M Applicable Lights : LED pixel strip Controled Method : APP Control

DOMRAEM Origin : China Item Type : RGB controler Product Size : 109.5X46X17.5mm Product Name : WLED Strip Light Controller 1-ch lc Qty : 800 ICs (WS2811/WS2812B/WS2813/WS2814/WS2815/WS2805/SK6812) 4-ch lc Qty : 3200 ICs(WS2811/WS2812B/WS2813/WS2814/WS2815/WS2805/SK6812)

DOMRAEM ESP32 WLED 4 Outputs Addressable Controller                DOM-Z-103/104 (5V-12V-24V 16A FUSE)This controller features convenient wiring terminals and 4-channel output, offering easy connection and flexible control. It comes with the open-source WLED firmware pre-installed, supporting over 16 million colors. You can directly operate it via iOS or Android devices to effortlessly create stunning DIY lighting effects.Note: This link includes three models, please select your desired product carefully

WLED Remote Only, Model: DOM-WLE-RC005. Designed for WLED series products only, cannot be used independently.

ESP32 4CH No Mic, Model: DOM-Z-103. 4-channel output without microphone and UART, built-in 16A fuse and level shifter.

ESP32 4CH with Mic, Model: DOM-Z-104. 4-channel output with microphone, no UART port, built-in 16A fuse and level shifter. Features4-Channel Output with Built-in 16A FuseFeatures 4 independent channel outputs and a built-in 16A fuse. It supports a maximum 16A high-power output to steadily drive ultra-long LED strips. With an ultra-low standby power of only about 0.6W, it is power-saving and highly energy-efficient.100+ Light Modes & Sound Activated ControlPreinstalled WLED firmware offers more than 100 vivid lighting effects including rainbow gradient and breathing light. Built-in mic realizes music sync lighting that reacts to surrounding sound. Support mobile and web remote control, and segmental light effect setting.Gateway-Free Wireless OperationDirect wireless control via exclusive WLED App on smartphone. No extra gateway required, easy installation and simple daily use.Broad Compatibility & Durable StructureFits common LED strip models: WS2811, WS2812, WS2812B, WS2813, WS2814, WS2815, WS2805, SK6812, SK19703, SK16703, SM16703SP3, FL19308, FW1935, TM1814, APA102. Works with DIMMER, CCT, RGB, RGBW, RGBCCT light types. Adopts ESP32 core chip and high-speed processing chip, matched with premium capacitors to ensure steady signal and lasting running performance.Product SpecificationsModel: DOM-Z-103/104

Input Voltage: 5V-12V-24V Max Output Current: 16A (Total) Pixel Support: 800 per channel, 3200 total (4 channels) Compatible Strips: WS2811, WS2812/2B/3/5, SK6812, APA102, etc. Dimensions: 109.5 × 46 × 17.5mm
