Feature:
1. MEASUREMENT CONTENT: Industrial microscope camera can measure straight line, line spacing, vertical line, rectangle, polygon, angle, arc, radius drawing circle, circle margin, arbitrary line, text annotation, etc.
2. CLEAR IMAGE: Digital microscope camera built in newly developed forARM dual core architecture, improve image clarity. Bring HD photo, video and preview playback
3. OUTPUT MODE: 4K industrial camera support 4K output image, real time frame rate 30FPS, equipped with High Definition Multimedia Interface, USB synchronous output
4. SENSITIVE AND LOW NOISE: Industrial microscope camera is equipped with high performance photosensitive chip, low noise, high sensitivity, and real color
5. SUPPORT FUNCTIONS: USB digital microscope camera support U disk storage function, can be connected to mouse. Support 10X digital amplification, support for the same screen comparison, support for 4 screen comparison
Specification:
Item Type: Industrial Microscope Camera
Output Mode: High Definition Multimedia Interface, USB
Pixels: 8.3MP
Sensor Size: 1 1.8, for IMX334
Pixel Size: 2.0micrometer x 2.0micrometer
Resolution Frame Rate: 3840X2160 at 30FPS, 1920X1080 at 30FPS
Magnification Setting: Display magnification in real time
Image Storage: U disk
Video: 4K(30 frames), 1920X1080(30 frames)
Exposure: Automatic and manual
White Balance: Auto or a click
RGB: Red, green and blue independently adjustable, color temperature adjustable
Mirror Settings: Black and white, horizontal mirror, vertical mirror
Grid Line: Support 8 groups of horizontal and vertical lines, color optional(red, blue, green, sky blue, orange, yellow, white, black) line can be moved, can set the center cross line, 4 kinds of line width optional
Image Adjustment: Brightness, contrast, saturation, sharpness, noise reduction, prevent flicker
PC Software: For KOPPACE VIEW(support photography, video, measurement)
Power Supply: DC12V 1A
Camera Port: C port
Languages: Chinese, English, Traditional
Digital Amplification: Support 10X Digital amplification
Same Screen Comparison: Support 2 screen and 4 screen comparison
Measurement Functions: Straight line, line spacing, vertical line, rectangle, polygon, angle, arc, radius drawing circle, circle margin, arbitrary line, text annotation and so on
Mouse Battery: 1 x AA battery(not included)
Working Voltage: 100 240VAC.
Package List:
1 x 4K Camera1 x High Definition Multimedia Interface Cable1 x USB Cable1 x CD1 x Plug1 x Mouse(battery not include)1 x Measuring Scale Ruler1 x Storage Box1 x User Manual
