ATTE IPUPS-16-20-R5U0 16-Port PoE Backup Power Kit for IP Cameras

ATTE IPUPS-16-20-R5U0 16-Port PoE Backup Power Kit for IP CamerasATTE IPUPS-16-20-R5U0 16-Port PoE Backup Power Kit for IP CamerasATTE IPUPS-16-20-R5U0 16-Port PoE Backup Power Kit for IP CamerasATTE IPUPS-16-20-R5U0 is a complete buffer power supply kit for IP surveillance systems with a 16-port PoE switch and two Gigabit uplink ports. It is designed to provide backup power for systems using up to 16 IP cameras and other network devices compatible with PoE 802.3at/af or PoE PASSIVE.

The integrated electronic protection independently safeguards the PoE outputs against overloads and short circuits. When a fault is cleared, the affected output can automatically restore power. The system also allows the PoE supply to be switched off individually on ports LAN_1 to LAN_8 using DIP switches.

The kit is suitable for installations requiring increased network throughput, including 4K Ultra HD CCTV systems. The power supply and battery backup support uninterrupted operation during temporary mains power failures, provided that suitable batteries are installed.

Key features

Support for up to 16 PoE receivers

Compatibility with PoE 802.3at/af and PoE PASSIVE devices

16 × 10/100 Mbps RJ45 LAN ports with PoE

2 × Gigabit RJ45 uplink ports

Electronic overcurrent and short-circuit protection for PoE outputs

Automatic power restoration after a fault has cleared

Up to 40 W per port on LAN_1 to LAN_8 in PoE PASSIVE mode

Optical indicators for power supply and data transmission status

Two selectable charging current values: 1 A or 2 A

Space for two 12 V, 18 Ah gel or AGM batteries

Modular construction for convenient servicing and system expansion

Installation in a 19-inch RACK cabinet

Technical specification

LAN ports: 18 × RJ45, including 16 × LAN + PoE 10/100 Mbps and 2 × Gigabit uplink

PoE 802.3af: up to 15.4 W on LAN_1 to LAN_8 with input voltage above 48 VDC

PoE 802.3at: up to 30 W on LAN_1 to LAN_8 with input voltage above 48 VDC

PoE PASSIVE: up to 40 W on LAN_1 to LAN_8

PoE mode: PASSIVE, Mode B, pins 4,5+ and 7,8−

PoE output protection: 0.75 A electronic protection with automatic reset

Power supply: 2 × AUPS-70-120-OFZ switching power supply

Continuous power output: 2 × 72 W, 144 W total, dynamically shared with battery charging

Maximum PoE output power budget: 130 W

Power supply efficiency: 90% at 120 W

Output voltage: 12 V ±15%; PoE supply voltage: 48 V ±2%

Input voltage range: 180–240 VAC

Battery protection: disconnection below 10.2 V

Rack enclosure ABOX-R5U0 is made of metal and finished in graphite RAL 7024. Its system mounting perforation enables vertical or horizontal installation of compatible modules in the available mounting area. The enclosure includes rear cable passages, additional cable routing space between the body and front cover, and room for storing spare cable lengths.

The front cover can be fitted and removed without tools. The kit is supplied with an electrical connector and a fuse block, while the enclosure is secured for installation in a 19-inch RACK cabinet using the included M6 screws. The housing measures 440 × 220 × 180 mm, corresponds to 5U, weighs 3.5 kg and has an IP20 protection rating.

Operating conditions include an ambient temperature range of −10°C to +40°C. The system is supplied without batteries; the enclosure provides space for two 12 V, 18 Ah gel or AGM batteries.502.30Atte
