Joom: Безопасная зарядка вашего электровелосипеда или электроскутера
• Не оставляйте аккумулятор без присмотра, когда вы находитесь вне дома или спите.
• Не накрывайте зарядные устройства или аккумуляторные блоки во время зарядки.
• Не перегружайте розетки и не используйте неподходящие удлинители.
• Не заряжайте и не храните аккумуляторы под прямыми солнечными лучами или в помещениях с температурой выше 45⁰C.
• Не заряжайте аккумуляторы вблизи горючих материалов или опасных веществ.
• По окончании зарядки всегда отключайте зарядное устройство от сети.
• Всегда используйте только оригинальное зарядное устройство, подходящее для данного аккумулятора.
• Всегда обращайтесь к профессионалам при переоборудовании вашего электровелосипеда или электроскутера.
• Всегда проверяйте аккумулятор (и зарядное устройство) на наличие видимых повреждений.
-----
Battery: 48V 20Ah (960Wh) Panasonic 21700 lithium battery
Motor: 500W brushless toothed high-speed motor, 60N · M torque
Motor brand: BAFANG - a globally renowned motor brand
Display screen: 4.5-inch LED color APP display screen (Bluetooth connection)
Speed sensor: 48V speed sensor
Charger: 54.6V 2A, input voltage 100-240V
Car lights: wired headlights+taillights
Transmission system: Shimano 7-speed
Positioning flywheel: Shimano 7-stage positioning flywheel
Front fork: Adjustable hydraulic shock absorber front fork
Crank: 170mm × 48 teeth
Pedal: Folding plastic pedal
Frame material: Steel alloy (45 # steel)
Seat tube: iron 34cm × 3cm, with scale/clamp
Saddle: with clamp saddle
Wheel rim: Aluminum alloy integrated wheel rim
Tire: 20 x 4.0 inches snow/all terrain fat tire
Tire pressure: 210 kPa
Mud board: PVC plastic mud board
Vertical pipe: Foldable telescopic vertical pipe (only the vertical pipe can be adjusted, the frame cannot be folded)
Handlebar material: carbon steel
Waterproof rating: IPX5
Maximum climbing angle: 20 °
Range: 80-130 km
Speed mode: 1st gear 15km/h/2nd gear 18km/h/3rd gear 25km/h
Charging time: 8-9 hours
Net weight: 35.2 kg
Gross weight: 41.2 kg
Unfolding size: 171 × 60 × 130 cm
Folding size: 143 × 31 × 71 cm (only after folding the foot pedal/riser)
Handlebar height: 120-130 cm (adjustable)
Saddle height: 85-105 cm (adjustable)
Suggested height: above 160 cm
Maximum load capacity: 120 kg
Drive mode: rear wheel drive
Cycling mode: pedal assisted/pure electric
Braking system: Front and rear power-off hydraulic disc brake
Battery disassembly: detachable
Accompanying accessories: mudguard/rear shelf/air pump
🏆 Core Selling Point
1️⃣🔋 Ultra long battery life -960Wh large capacity battery
Panasonic 21700 battery cell, capable of running 80-130 kilometers on a single charge
Using Panasonic 21700 high-quality battery cells, with high energy density and long lifespan
960Wh large capacity, meeting long-distance commuting or all day outdoor exploration needs
Detachable design, battery can be carried home for charging, no need to drive the whole car upstairs
Excellent low-temperature performance, maintaining good discharge efficiency even at -20 ℃ environment
2️⃣ ⚡ Powerful power - Eight sided 500W motor+60N · M torque
Climbing on snow is effortless, with a maximum climb of 20 °
BAFANG is an international first-line motor brand with reliable quality
Brushless toothed high-speed motor, fast starting and linear acceleration
60N · M ultra high torque, easily handling snow, sand, mud, and steep slopes
Rear wheel drive design, more stable center of gravity, stronger snow grip
3️⃣ 🛞 20 × 4.0-inch oversized fat tire - Snow King
Conqueror of all terrains, with snow, sand, and mud as smooth as walking on flat ground
4.0-inch ultra wide tread, increasing ground contact area to prevent snow/sand entrapment
Low tire pressure design (210kPa) provides excellent cushioning and grip
Aluminum alloy integrated wheel rim, lightweight and sturdy, reducing unsprung weight
Even on snowy, icy, and gravel roads, it remains stable
4️⃣ 🛑 Hydraulic disc brake+power-off protection - safe braking on icy and snowy roads
Front and rear hydraulic disc brakes, capable of braking in snowy conditions
Hydraulic disc brake has strong braking force and linear feel, which is superior to mechanical disc brake
Power off braking function: Pressing the brake automatically cuts off the motor power and shortens the braking distance
Braking on wet/icy roads remains stable and reliable
5️⃣ 📱 Intelligent APP Color Screen - One handed Control
4.5-inch LED color display screen+mobile APP interconnection
Large screen anti glare design, still clearly visible under strong snow light
Bluetooth connection to mobile app, adjustable parameters, record trajectory, and view battery level
Real time display of speed, mileage, battery level, gear and other information
6️⃣ 🔧 Adjustable hydraulic shock absorber front fork - filtering bumps
Snow, frozen soil, and bumpy roads do not shake hands
Hydraulic shock absorber front fork effectively absorbs road impact
Adjustable damping, freely adjust softness and hardness according to road conditions and weight
Protecting wrists and spine, making long-distance cycling more comfortable
7️⃣ ⚙️ Ximano 7-speed transmission - precise and smooth
Shimano professional variable speed, 30% effortless climbing
Ximano 7-speed positioning flywheel, precise and smooth gear shifting
In the assist mode, the gear ratio can be freely switched according to the slope
More labor-saving and efficient than ordinary single speed cars
8️⃣ 🏗️ High strength steel alloy frame - load-bearing capacity of 120kg
45 # steel alloy frame, sturdy and durable
The frame is non foldable, with stronger overall rigidity and excellent torsional resistance
More suitable for high-intensity snow/off-road use, with no abnormal noise from the body
Maximum load capacity of 120kg, capable of carrying equipment or carrying passengers
Only the upright tube can be folded and extended, making it convenient for riders of different heights to adjust
9️⃣ 🌧️ IPX5 waterproof+all inclusive mud board - no worries about melting snow
Pressure over puddles and melted snow mud without short circuiting
IPX5 waterproof rating, rain and splash proof
PVC extended mud board effectively blocks mud and snow splashing, keeping clothes clean
Cycling in winter is more relaxed
ten 🎒 Rich Accessories - Ready to Use Out of the Box
Fenders, rear shelves, and air pumps are all standard equipment
The back shelf can be used to mount ski and pack bags
Complete accessories, no additional purchase required
🎯 one-sentence summary
The frame is non foldable, with stronger rigidity and more stable off-road performance in snowy conditions! With a super large 960Wh battery, an eight sided 60N · M motor, and 4.0-inch fat tires, it can still traverse snowy terrain at minus 20 degrees Celsius! ” ❄️🚴♂️
