BJX DC:10-30V Sensing Distance 30M Response Time:Max. 1ms Photoelectric Switch Sensor Through-beam NPN PNP NO NC

High-concerned chemical：None isCustomized：Yes Theory：Optical Sensor Material：Polymer Type：Optical-Electronics Sensor Output：Switching Transducer Brand Name：NoEnName_Null Origin：Mainland China Sensing distance：3-5m Sensing target：Opaque material of min. 015mm Light source：Red LED(660nm) Response time：Max. 1ms Power supply：10-30VDC Current consumption：Emitter/Receiver: Hax. 20mA Sensitivity adjustment：Sensitivity adjuster Operation mode：Light ON/Dark ON(set by switch) Control output：NPN PNP NO NC Connection type：04mm,3-wire,2m (emitter of through-beam type: 04mm, 2-wire. 2m)(AWG26, core diameter: 0.52mm, number of cores: 20, insulator out diameter: 0lmm) Environment Ambient illuination：Sunlight: Max 11.0001x Incandescent amp: Max 3001x received ilumination) Environment Ambient temperature：-25 to 60 Cstorage -40 to 70C Protection structure：IP65(IEc standard) EnvironmentAmbientHumidity：35 to 85% RHstorage: 35 to 85% RH Hysteresis(distance)：Max. 20% of sensing distance Accessories Common：Mounting bracket, M3 bolt: 2, adjustment screwdriver

High-concerned chemical: None isCustomized: Yes Theory: Optical Sensor Material: Polymer Type: Optical-Electronics Sensor Output: Switching Transducer Brand Name: NoEnName_Null Origin: Mainland China Sensing distance: 3-5m Sensing target: Opaque material of min. 015mm Light source: Red LED(660nm) Response time: Max. 1ms Power supply: 10-30VDC Current consumption: Emitter/Receiver: Hax. 20mA Sensitivity adjustment: Sensitivity adjuster Operation mode: Light ON/Dark ON(set by switch) Control output: NPN PNP NO NC Connection type: 04mm,3-wire,2m (emitter of through-beam type: 04mm, 2-wire. 2m)(AWG26, core diameter: 0.52mm, number of cores: 20, insulator out diameter: 0lmm) Environment Ambient illuination: Sunlight: Max 11.0001x Incandescent amp: Max 3001x received ilumination) Environment Ambient temperature: -25 to 60 Cstorage -40 to 70C Protection structure: IP65(IEc standard) EnvironmentAmbientHumidity: 35 to 85% RHstorage: 35 to 85% RH Hysteresis(distance): Max. 20% of sensing distance Accessories Common: Mounting bracket, M3 bolt: 2, adjustment screwdriver
