Features:
High quality gear The gear is ground after heat treatment, which has the advantages of long wear resistance, long life, low noise, high accuracy, high efficiency, stable performance, corrosion resistance and easy installation.
Metal material The motor is made of all metal material, making it more wear resistant and rust free. It is durable and the motor box is also self developed.
Pure copper coil The copper wire has super conductivity, which makes the motor has steady and strong power output, the three layer high density molecular paint dripping paint coating, effectively isolates dust, high temperature resistance, life is 10 times of the ordinary coating, and the rotor part adopts pure copper group of small resistance.
Professional and practical design with beautiful appearance, easy to carry and use.
The motor has high torsion, and the starting current of the high power motor is relatively large.
Specification:
Rated Voltage :6V
Reduction Ratio(
Optional
)
6.3
10
19
30
56
90
131
168
270
506
810
No Load Current(A)
less than 0.9
less than 0.9
less than 0.9
less than 0.9
less than 0.9
less than 0.9
less than 0.9
less than 0.9
less than 0.9
less than 0.9
less than 0.9
No Load Speed(RPM)
1150
725
380
240
130
80
55
43
26
14
9
Rated Torsion(kg.cm)
0.5
0.9
1.6
2.5
5
7.5
11
14
20
25
30
Rated Speed(RPM)
1000
600
250
150
100
60
50
30
20
10
5
Rated Current(A)
less than 1.5
less than 1.5
less than 1.5
less than 1.5
less than 1.5
less than 1.5
less than 1.5
less than 1.5
less than 1.5
less than 1.5
less than 1.5
Stopping Current(A)
3
3
3
3
3
3
3
3
3
3
3
Length of L
19
22
24
26.5
29
Package List:
1*Speed Reduction Geared Motor
Note:
The motor is a large torsion one, the starting current of the high power motor is relatively large, and the 6V starting flow is around 3A.
After starting, the current will return to normal 1 2A, so you should choose a high power power supply when purchasing this motor.
The 6V motor is better to choose a 5A power source, otherwise the motor will not start! The motor rotates at a higher speed.
All metal gears, the sound is too large.The torsion of the motor itself is more than 35KG for large gears. Do not block or reverse the moment.
