Joom: Безопасная зарядка вашего электровелосипеда или электроскутера
• Не оставляйте аккумулятор без присмотра, когда вы находитесь вне дома или спите.
• Не накрывайте зарядные устройства или аккумуляторные блоки во время зарядки.
• Не перегружайте розетки и не используйте неподходящие удлинители.
• Не заряжайте и не храните аккумуляторы под прямыми солнечными лучами или в помещениях с температурой выше 45⁰C.
• Не заряжайте аккумуляторы вблизи горючих материалов или опасных веществ.
• По окончании зарядки всегда отключайте зарядное устройство от сети.
• Всегда используйте только оригинальное зарядное устройство, подходящее для данного аккумулятора.
• Всегда обращайтесь к профессионалам при переоборудовании вашего электровелосипеда или электроскутера.
• Всегда проверяйте аккумулятор (и зарядное устройство) на наличие видимых повреждений.
-----
⭐Main Features
⚙️1000W*2 Dual Motor ( Top speed: 25km/h )
Both the front and rear are equipped with dual 48V 1000W high-speed brushless motors, which are lightweight. The internal star gear design can amplify torque and improve the energy efficiency conversion rate.
📐 45° Max Climbing
The 48V 2000W brushless motor provides the power to ride in max climbing 45°. Its internal use of star gear design,improving speed performance and climbing performance.
🔋48V 20Ah (960Wh) Lithium Battery (Samsung Cell Units)
48V 20AH 21700 Lithium Battery, Completely Hidden In The Frame, Waterproof And Dustproof, Double Protection, Strong Output, Always Stable. Pure Electrician Reach 70km, Assisted Riding Can Reach 130km.
🛞26 x 4.0 Inch Fat Tires
Equipped with 26*4.0 inch wheels, the bike effortlessly navigates large potholes and muddy terrain, smoothly clearing speed bumps. The tires, featuring anti-skid and anti-vibration capabilities, contribute to a more comfortable, longer-lasting ride that is swift and requires minimal effort.
🚀Shimano 7-speed Gears
The Shimano 7-speed freewheel system allows you to shift up to a larger cog for uphill riding and downshift to a smaller cog for high-speed travel. Combined with the pedal-assist system, it enables you to adjust your speed appropriately to complete your journey efficiently.
📱Colorful smart LCD Display
The Smart LCD display features a new interactive interface with an LCD display, integrated gear switching, driving data detection, and power output settings, making it clear at a glance. It has an IP64 rating for waterproof and dustproof performance and is of reliable quality. Additionally, a password can be set for added security.
📊Specifications
FRAMESET
Frame: 6061 Aluminum Alloy Soft Tail Frame
Fork: Lockable aluminum shoulder oil spring suspension large forks, travel 120 mm
Rear Suspension: pneumatic rear shock absorber
Handelbar Sets: 31.8 Big Swalow handlebars
Cranksets: Aluminum alloy crank square hole 46T
Rim: Aluminum alloy wheels
Brake: 180MM DYISLANDDe-energized Hydraulic Disc Brakes
Tyre: 26*4.0 Fat tires
ELECTRONICS
Motor: 48V 1000W front drive brushless motor and 1000w rear drive brushless moto, max torque 95Nm
Battery: 48V 20AH Samsung Lithium Battery, 21700cells
controller: 48v36a dual drive vector controller
LCD Display: Color LCD with speed, trip, battery, assist level and more
Front light: 4.5 "LED high brightness headlights
Charger: 48V 3A charger
Throttle: Half Twist
Power assist Sensor: 12-point Holzer-intensive speed sensor
Waterproof Grade: IP54 (waterproof for daily use, suitable for use in rain)
SPEED & RANGE: Riding conditions tested: After being fully charged, the load is 60kg, the temperature is 25 ℃, and the test is conducted at 20km/h. The actual measurement is the average speed on a flat road surface
Pure electric mode: 55-70 km
Pedal Assist Mode: 100-130KM
Gear Systems
Variable speed: Shimano 7 speed
Shifting Lever: Shimano M315-7 finger dial
Rear Derailleur: Shimano M310
Chain: KMC 7s
WEIGHT& LOAD
Bike Weight: 43KG (94lbs)
Max Bike Load: 180KG(400lbs)
Rear rack Load Capacity: 30KG(60lbs)
