Features:
QX10 network HD outdoor waterproof ball machine, reliable and durable in use.
Built-in wifi module, TF card slot, can have the function of wireless connection and local recording.
Low-rate network HD shaking machine, support independent mobile phone, computer real-time monitoring.
Smart H.264 video encoding, 1080P real-time image transmission, adaptive network, up to 25/30 frames/sec smooth experience.
Echoing cancellation and noise suppression technology, perfect half-duplex voice effect, support 180 degrees rotation of the screen.
Self-contained intelligent P2P penetration technology, one-button remote control, and plug and play.
Lattice six lights (2 red + 4 infrared), maximum night vision distance can be up to 15 meters.
PTZ outdoor installation, all-round no-blind angle monitoring, suitable for home, office, school, shopping malls and other occasions.
Support 433 connection to smart home suite, multi-users remote preview, and cloud storage. Compatible with mainstream for NVR devices such as for Haikang and for Dahua.
Specifications:
Main Processor: FH8632V2
Material: ABS Plastic
Voltage: 110-240v
Optional Plug Type: US Plug, EU Plug, UK Plug, AU Plug (optional)
Operating System: Embedded LINUX Operating System
Image Sensor: 2 MPx CMOS
Image Coding Standard: Smart H.264
Monitor Image Quality: 1920*1080/640*360
Support: Image motion detection, cloud storage, remote playback, 433 protocol, WIFI
Recording Mode: manual recording, timed recording, alarm recording
Video Storage: computer / mobile phone/TF card (maximum support 128GB)
Alarm Trigger: video push, human tracking, voice alarm reminder + red light flashing, alarm recording
Wired Network Port: RJ-45 10-100MB adaptive Ethernet interface
Wireless Network: 802.11b/g/n
Network Protocol: Support TCP/IP, RTSP, Onvif, etc.
WIFI Networking: scan code + AP distribution network + acoustic wave distribution network
Power Supply: DC 12V
2A
Power Consumption: <24W
Operating Temperature: -10 celsius ~ + 50 celsius
Operating Humidity: 10percent -90percent
Lens: 3.6MM HD lens
Light Board: dot matrices 6 lights (2 red lights + 4 infrared lights)
Package Included:
1 * Outdoor PTZ Camera
1 * Waterproof Kit
1 * Power Source with Wire
1 * Screws Package
1 * User Manual
