【Voltage Compatibility】
When using electrical appliances, please note that they are designed for Japanese voltage specifications (90-110V), so if you use them with a different voltage, it may cause a malfunction.
【Plug Type】
Our products use Japanese plug types (A or B type).
Please use a conversion adapter if necessary.
【Important Note on Transformers and Adapters】
A transformer adjusts voltage to match your device’s requirements.
A conversion adapter only changes the plug shape and does not adjust voltage.
Using only a conversion adapter without a transformer may result in damage to the product.
【Liability】
We are not responsible for malfunctions or damages caused by improper use, such as operating the product without a transformer.
----------------------------------------------------------------------
“ELECOM GAMING V custom” is ELECOM's new high-class gaming device series that is aimed at all players, from professionals to entry-level players, who are particular about winning, and delivers “winning devices” that are perfect for each player, carefully crafted not only for numerical performance but also for sensory comfort.
This is a 65% size gaming keyboard equipped with a magnetic analog detection switch (magnetic switch) that allows you to turn key input ON/OFF with a minimum push or push of 0.1mm.
Equipped with the "ELECOM Magnetic S.P.S Engine" which adds a variable actuation point/reset point control system to ELECOM's gaming keyboard engine, which has improved response speed, precision, and stability for key input.
A new magnetic switch allows the actuation and reset points to follow and change positions whenever and wherever the key is pressed. This makes it possible to turn on the moment you push it in and turn it off the moment you push it up, allowing for faster positioning and stopping than traditional mechanical keyboards.
The push/push amount that turns the key ON/OFF can be set in 0.1mm increments from 0.1mm to 3.8mm as "sensitivity" using the dedicated setting software "EG Tool". This sensitivity can be set for the entire keyboard at once, or for specific keys individually.
[Specifications] ■ Connector shape: USB-A plug ■ Connection method: USB wired ■ Compatible model: Windows computer equipped with a USB port ■ Compatible OS (Windows): Windows 11/10 ■Key layout: Japanese layout ■Number of keys: 71 keys ■Key pitch: 19.0mm ■Key type: Magnetic analog detection switch ■Key stroke: 4.0mm ■Actuation point: 0.1mm to 3.8mm ■Operating pressure: 30 to 60g ■Report rate: Max. 1000Hz ■Backlight: 16.77 million colors RGB lighting ■ Number of USB ports: 1 ■ Power supply: USB bus power ■ Cable length: Approx. 2.0 m ■ Size classification: 65% size ■ External dimensions: Width approx. 322.4 mm x Depth approx. 124.7 mm x Height approx. 36.2 mm (excluding stand), Width approx. 322.4 mm x Depth approx. 124.7 mm x Height approx. 48.0 mm (when standing) ■ Weight: Approx. 662 g *Cable not included ■Contents: VK600A main unit x 1, paracord cable x 1, replacement keycap x 6, keycap release x 1, V custom logo sticker x 1 ■VCCI: Class B compatible ■Color: White ■Warranty period: 2 years
