Feature:
1. Multifunctional: The audio extractor can be connected to TV or power amplifier, and high definition multimedia interface can be output at the same time with optical fiber, coaxial and lotus interfaces and ensure synchronous playback of audio and video.
2. HD Image Quality: The 4K HD image quality provides you with an immersive effect. The audio converter supports 4K and 2K HD image quality, with HD resolution, and the picture details can be clearly displayed.
3. HDR Technology: The HDR technology of this audio extractor splitter can reflect the visual effects in the real environment and provide you with a better use experience.
4. Strong Practicality: The audio extractor converter can connect bluetooth speakers to realize more free wireless listening to songs, which is very practical.
5. Widely Applicable: The audio extractor is compatible with many high definition multimedia interface devices, such as, set top boxes, computer, game machines, blue ray machines, TV, monitor, projectors, cameras and other products.
Specification:
Item Type: Audio extractor
Material: ABS, metal
Weight: Approx. 187g 6.6oz
Input Port: High definition multimedia interface x1
Output Port: High definition multimedia interface x1, optical fiber x1, R L RCA x1, bluetooth transmission
ARC Function: Support(Optical fiber, R L RCA, bluetooth output)
Resolution Format: 480P, 720P, 1080P, 2160P at 60, 50, 30, 25, 24
Support: HDR, for Dolby Vision
Color Depth: 8, 10, 12Bit at 480P, 720P, 1080P 8bit at 2160P
High Definition Multimedia Interface Audio Output Formats: for Dolby HD, DTS HD, for Dolby Atoms, for Dolby AC3, DTS, LPCM, etc
Optical Fber Audio Output Format: for Dolby AC3, DTS, LPCM2.0
Analog Audio Output Amplitude: 2V RMS
Bluetooth Version: Bluetooth V5.0
Bluetooth Working Frequency Band: 2.402 2.480GHz
Bluetooth Transmission Power: +12dBm(Max.)
Bluetooth Transmission Distance: < 15m 590.6in
High Definition Multimedia Interface Transmission Bandwidth: 25 600MHz
High Definition Multimedia Interface Transmission Rate: 0.75 18Gbps
High Definition Multimedia Interface Input Line Length: 2160P AWG 26 <5m 196.9in 1080P AWG 26 <10m 393.7in
High Definition Multimedia Interface Output Line Length: 2160P AWG 26 <5m 196.9in 1080P AWG 26 <10m 393.7in
Input Power Specification: DC 5V 1A
Maximum Working Current: 700mA
Product Size: 106x60x27.3mm 4.2x2.4x1.1in.
Package List:
1 x Host1 x Power Cord1 x Instructions
