Description:
Input voltage: AC 85V-265V
Input voltage: DC 100V-300V
Frequency range: 47HZ-63HZ
Standby power: <150mV/230VAC
3.3V:
Rated current: 1000mA
Current range: 0-1000mA
Rated power: 5W
Ripple: <150mV
Output accuracy: ±1
Voltage regulation rate: ±1
Load adjustment rate: ±1
Switch overshoot: 10
Size: Show in the picture
5V:
Rated current: 1000mA
Current range: 0-1000mA
Rated power: 5W
Ripple: <150mV
Output accuracy: ±1
Voltage regulation rate: ±1
Load adjustment rate: ±1
Switch overshoot: 10
Size: Show in the picture
9V:
Rated current: 500mA
Current range: 0-500 mA
Rated power: 5W
Ripple: <150mV
Output accuracy: ±1
Voltage regulation rate: ±1
Load adjustment rate: ±1
Switch overshoot: 10
Size: Show in the picture
12V:
Rated current: 400mA
Current range: 0-400 mA
Rated power: 5W
Ripple: <150mV
Output accuracy: ±1
Voltage regulation rate: ±1
Load adjustment rate: ±1
Switch overshoot: 10
Size: Show in the picture
15V:
Rated current: 300mA
Current range: 0-300 mA
Rated power: 5W
Ripple: <150mV
Output accuracy: ±1
Voltage regulation rate: ±1
Load adjustment rate: ±1
Switch overshoot: 10
Size: Show in the picture
24V:
Rated current: 200mA
Current range: 0-200 mA
Rated power: 5W
Ripple: <150mV
Output accuracy: ±1
Voltage regulation rate: ±1
Load adjustment rate: ±1
Switch overshoot: 10
Size: Show in the picture
Package include:
1Pcs Module
