Feature:
1. Multi-functional: It supports online programming, can be repeatedly burned and written, has built-in EEPROM, can copy ordinary remote controls of the same frequency, and can clear code and learn code at any time, which is convenient and fast to use.
2. High Sensitivity: The copy remote controller adopts high-performance RF chip, with plastic oscillator stable frequency and accurate frequency point. Long transmission distance, no directionality, high transmission sensitivity, no signal blocking.
3. Simple Operation: Most fixed code and learning code can be copied by wireless remote control, with fast copy speed and simple operation. After copying, the original remote control will not be affected. The copy is automatically matched and used directly without coding.
4. Wide Application: This intelligent copy remote controller is applicable to battery cars, unicycles, garage doors, access locks, lamp control, and security alarm.
Specification:
Color: black
Operating frequency: 433.92 MHz
Battery type: button battery 2032 * 1
Working mode: copy
Shell material: ABS
Product size: about 60 * 37.7 * 11mm/2.36 * 1.48 * 0.43inch (including shell)
Electrical parameters:
Working voltage: DC2.4-3V
Emission current:<12mA
Quiescent current:<0.1uA
Transmission power:+3-6dBm
Working temperature: - 20-70 Celsius
Function description:
Copy code checking operation
If the remote control has checked the code, the code can be checked only after the code is cleared. Code matching operation: press the single key of the copied remote control and the copy remote control at the same time, until the indicator light of the copy remote control changes from flash to constant light, then release the two remote control keys, and code matching is successful. keys are also operated in this way until all keys are copied.
Clear code operation
At the same time, press and hold the unlock and lighting keys of the copy remote control until the indicator light flashes quickly, and then press the unlock key three times to clear the code (the lighting key is kept pressed during this process).
Copy chip
PT2242, PT2260, PT2262, EV1527, 527, PT2240, SMC918, HT-12E, AX5326-3, AX5326-4, AX5026, HT600, HT680, HT6207, HT6010, HT6014, MC145026, HT640, etc
Matters needing attention
(1) The battery voltage cannot exceed the operating voltage range.
(2) When copying the remote control, try to keep the two remote controls close to each , otherwise the copy exception will occur.
(3) In the environment with large wireless interference, the remote control distance may be reduced.
(4) Keep out of reach of children.
(5) Do not use it in a humid environment, otherwise the remote control may be damaged.
Note:
1. The color of the item may be slightly different from the pictures shown on website caused by many factors such as brightness of your monitor and light brightness. Please refer to the actual product received.
2. Please allow slight manual measurement deviation for the data.
