▸ Fiber optic lighting: integrated high light transmittance fiber channel, life span ≥5000 hours, no heat source interference, field of operation
▸Precision direct drive: 1:1 transmission ratio → 40,000 RPM, zero torque loss
▸Needle compatibility: HP Φ2.35mm universal needle (clamping tolerance ±0.005mm)
▸Dynamic cooling: The internal waterway is sprayed directly to the tip of the needle, and the cooling efficiency is increased by 50%
▸Infection control: 135°C high temperature sterilization + E-type interface anti-suction design
▸Environmentally friendly: ≤70dB library-level mute (measured value 68dB)
▸Power requirements: 0.3MPa stable air source (compatible with 90% dental treatment tables)
Four golden application scenarios
1. Microscopic root canal treatment
Application operation：
Type C root canal exploration (optical fiber illuminates the medullary chamber)
Calcified root canal mouth exposed (internal cold water protects the pulp)
2. Minimally invasive repair and tooth preparation
Application operation：
Fine preparation of the subgingival shoulder platform (optical fiber exposes the dark area of the gingival groove)
Inverted and concave trimming of inlay holes (0.3mm needle, precise depth control)
3. Phase II implantation surgery
Application operation：
Healing abutment gingival formation (internal cold water prevents soft tissue burns)
Bone crest leveling (optical fiber assisted identification of bone defect boundaries)
4. Preservation and treatment of living marrow
Application operation：
Partial live marrow resection (precise removal of the coronary marrow, retaining the activity of the root marrow)
Micro-polishing of caries damage (optical fiber identification of discolored dentin)
Technical:
1. Optic fiber inner channel low speed handpiece
2. 1:1 ratio
3. Bur applicable:HP φ2.35mm
4. Supply Air Pressure: 0.3Mpa
5. Rotation Speed: 40,000r.p.m
6. Noise: ≤70dB
7. Autoclavable 135°C
8. Inner water spray
9. Optic fiber superior service life
10. Connect: ISO E-TYPE
Package:
Handpiece*1
English Operation manual*1
