Product introduction
When the battery is loaded, the vibration switch S1 is disconnected, so the circuit does not work. When rotating gyroscopic due to centrifugal effect, vibration switch S1 connected, the working principle of work, multivibrator circuit, when switched on, two triple tube Q1 and Q2 will be for the forerunner, but due to the differences of components, only one tube to the pilot, and then in the circuit two triode conduction and globe in turn, The two leds will emit light in a continuous cycle. When rotating the gyro, the bright LED will appear in a straight line, because the lights are staggered, and at the same time every two lights are alternately lit, so there are multiple dotted line shape pattern.
The line layout is compact and regular, with good electrical insulation and mechanical stability, and can maintain stable performance under different temperature and humidity environments to ensure accuracy and reliability.
In circuit design, carefully planned lines are like precision transportation networks, and lines of different widths and spacings undertake different currents and signals transmission tasks respectively. The key signal lines are impedance matching processing, which greatly reduces signal reflection and attenuation and ensures the stable transmission of high-frequency signals.
All kinds of electronic components are soldered on the circuit board, and the solder joints are full, round, and firm and reliable. Core components like chips are perfectly connected to the circuit board through fine packaging processes to achieve high-speed data processing and interaction.
This circuit board has a wide range of responses in many fields. Whether in the industrial control field that requires extremely high stability or consumer electronics field that pursues extreme performance, it can provide solid guarantees for the stable operation of the equipment with its excellent design and reliable performance, and help various electronic devices play a powerful role.
