Feature:
1. The ceiling lamp shell is made of high?quality aluminum + silica gel, with bright color and texture.
2. The luminous flux is 3000LM, high brightness, low light attenuation, no visible flicker, wide irradiation area, 30?40square meterscan be irradiated, low energy consumption, long service life.
3. Equipped with graphic instructions, a full set of accessories, easy to install and easy to use.
4. The base is made of high?quality iron, 4 LED lamp arms, made of aluminum alloy and silicone, sturdy and durable, long service life, and high quality.
5. The unique simple design, coupled with natural cold light, is suitable for study, dining room, office, bedroom, study, coffee shop and other places.
Specification:
Item Type: Ceiling Light
Material: Iron + Aluminum + Silicone
Weight: Approx. 712g / 25.1oz
Purpose: Home lighting
Combined Width: Approx. 55cm / 21.7in
Combined Height: Approx. 6cm / 2.4in
Lamp Holder Diameter: Approx. 14cm / 5.5in
Input Voltage: AC85-265V
Light Color: white light
Number of LEDs: 35 LEDs for a single strip, 140 LEDs for four strips (35x4)
Power: 25W
Brightness: 3000LM
Color Temperature: 6000-6500K
Shell Color: silver
Irradiation Area: 30-40square meters
Service Life: 50000H
How to Use:
1. Install the base fixing frame-remove the fixing frame from the lamp chassis, and then use the expansion screw tube and screws to install the fixing frame on the ceiling.
2. Install the lamp tube and the ground wire-pass the screw on the lamp tube through the small hole on the lamp holder in turn, fix it with a gasket and screw, and install the ground wire and one of the lamp tubes together.
3. Lamp adjustment, parallel combination.
4. Install the wiring-connect the lamp wiring and the power adapter in series, and the male head to the female head are connected in series.
5. Install the power cord-first cut off the power, and then connect the other end of the power adapter to the power supply, the voltage is AC85-265V.
6. Finally, unscrew the screws on the base fixing frame, align the base with the fixing frame, and use the unscrewed screws to connect with the fixing frame through the small holes on the base.
7. Complete the installation, turn on the power supply, and turn on the lights (for detailed graphic tutorials, please refer to the manual)..
Package List:
4 x Light Tube1 x Power Adapter1 x Lamp Chassis1 x Manual1 x Wrench4 x Gasket4 x Screw Cap1 x Installation Bag (2 x Pointed Screws, 2 x Screw Expansion Tube)1 x Yellow Ground Wire
