Joom: Safely charging your e-bike or e-scooter
• Don’t leave your battery unattended while charging, when you're out or while you're asleep
• Don’t cover chargers or battery packs when charging
• Don’t overload sockets or use unsuitable extension chords
• Don’t charge or store batteries in direct sunlight or in areas with temperatures above 45⁰C
• Don’t charge batteries next to combustible materials or hazardous substances
• Always unplug your charger once you have finished charging
• Always make sure to only use the proper proprietary charger
• Always ask a professional when converting your e-bike or e-scooter
• Always check your battery (and charger) for visible damage
-----
Pixar Space 26"x4.0" All-Terrain Electric Bike
If you need to override the speed limit, please watch the video. Thank you.
⚡ [500W Motor]
The powerful 500W motor delivers fast and smooth power, providing ample torque for climbing steep slopes and on rough terrain, giving you confidence in every acceleration.
🚀 [25 km/h (Can be adjusted to 32 km/h)]
The factory setting complies with safety regulations. Adjusting the speed limit allows for even higher speeds, but please ensure this is done legally and safely.
🔋 [48V 20AH Battery]
Equipped with a large-capacity 48V 20AH lithium battery, it provides a solid foundation for long-lasting range and powerful power output, allowing you to explore further.
🛣️ [Pure Electric 40-60km | Assisted 70-100km]
In pure electric mode, you can reach a range of 40-60km; in assisted mode, the range increases significantly to 70-100km, meeting your diverse needs from daily commuting to long-distance hiking.
⚙️ [Shimano 7-Speed]
Equipped with a reliable Shimano 7-speed shifting system, you can precisely handle high-speed cruising on flat ground and climbing steep slopes, allowing for flexible riding strategies.
💪 [Maximum Load of 120kg]
The sturdy frame structure and reinforced load-bearing design ensure a maximum load capacity of 120kg, ensuring a stable load for both the rider and their gear.
Product Specifications：
Frame: 6061 aluminum alloy
Wheel Size: 26 x 4 inches
Wide tires: Chaoyang brand
Motor: 48V 500W high-speed hub motor
Battery: 48V 20AH (EVE brand)
Mileage: 60-100 km
Display: Multi-function LCD
Maximum Speed: 25 km/h (unlockable to 32 km/h)
PAS: 5 electric modes
Suspension: Front fork
Sensor: Speed sensor; 12-speed
Charger: 54.6V 3A
Charging Time: 6 hours
Derailleur: Shimano 7-speed
Brake: Mechanical disc brakes
Light: Front and rear lights
Fender: Front and rear fenders
Waterproof: IP54 rating
Loading Capacity: 120 kg
Box Size: 103 x 47 x 83 cm
Net Weight: 31.5 kg
Gross Weight: 34.5 kg
