Features:
2.4G MODE
For initial use, plug a USB receiver into the USB port of the device and wait for 20-60 seconds to install the driver of the USB receiver. Moving the mouse so the mouse cursor can move on the screen means that pairing is successful; if it is unsuccessful, press and hold the [ OK and [ BACK ] buttons, the LED light begins to flash. Pairing is successful when the LED light stops flashing
BT 5.0 MODE
1. Before using this device, first you must turn on the BT function of the lain device
2. Then long-press the OK + Return keys, when the LED turns to flash quickly, the product enters the pre-pairing mode.
3. Click Add Aearch new devices on the main device to find this air remote's name ( Example: BT-REMOTE ). Click the name to connect
4. After the product is successfully connected, the direction of the mouse pointer can be controlled by waving in the air
5. If the connection is not successful, please perform the operation steps of items 2-4 again
6. Reconnect efficiency description: The normal reconnect time of this product is 3-5 seconds after it is normally paired with the main equipment
7. This product can only remember the pairing information of one main device. when the product is connected to a new device, the connection of historical devices is not supported after
8 . In this case. You need to delete the historical connection information of this peripheral can be successfully matched for a new search
CPIADJUSTMENT
CPI ( Count Per Inch ). Speed of the Mouse Cursor
Adjustment ( 3 Levels ), 1, 2, 3 Level. The higher the level, the faster the speed. The default speed is set at level 2
1 . Speed Increase
Press the OK button + Volume + ] button for about 3 seconds, the work indicator flashes quickly and then goes off, release the button, CPI on the basis of the original increase 1 level
2 . Speed Decrease
Press [ OK ] + Volume - for about 3 seconds, the work indicator flashes quickly and then goes off, release the button, and CPI is reduced by 1 level on the basis of the original
Specifications:
Standby power consumption: 25ua
Remote control distance: 8-10m
Charging port: Micro USB
Overall dimension: 155*45* 9mm
Battery type: 250mah /3.7V lithium battery
Support system: Android /Windows /Mac OS/Linux
Wireless modulation mode: GFSK
Modulation frequency: 2.4- 2.4835GHz
Working temperature: -20 C-65C
Number of keys: 58
Power consumption:15ma
Package Includes:
1*M5 Wireless Keyboard
1*USB Cable
1*USB Dongle
1*User Manual
